Epson TM-M30III

Name: Epson TM-M30III
Brand: Epson
Price: 264.99 USD
Availability: InStock

Images may not reflect the actual product

TM-M30III (iOS)

TM-M30III - iOS Compatible Thermal Receipt Printer (USB, Bluetooth, WiFi) The OmniLink TM-m30III combines reliable performance with a compact, water-resistant design, all housed in an aesthetically pleasing enclosure. This compact thermal receipt printer can print from web-based applications using Epson's ePOS™ Print technology or leverage Epson® Server Direct Print technology for online ordering and remote printing.

• Software: Shopify, Lightspeed
• Max Print Width: 3 Inches
• Warranty: 2-Year
• Return Period: 15 Days
• Lifetime Support
• Free Shipping

Compact receipt printing with a built-in POS hub

The Epson OmniLink TM-m30III is a compact 3-inch receipt printer for mobile POS. Front or top paper exit, mobile-device charging and network tethering let it serve as both a receipt printer and a connection point for a tablet-based system.

Key Specifications

Print method: Direct Thermal
Print speed: Up to 300 mm/sec
Paper widths: 80 mm or 58 mm with included guide
Resolution: 203 dpi
Interfaces / connectivity: USB and Ethernet; built-in Wi-Fi and Bluetooth on wireless models
Cutter and reliability: Full or partial cut; rated for 2.2 million partial cuts
Platform support: iOS, Android, Windows, macOS and Linux with compatible software
Dimensions and weight: 127 × 127 × 130 mm (top exit); 127 × 128 × 129 mm (front exit), W × D × H; 1.3 kg
Warranty: 2 years

In the Box

Selected TM-m30III or TM-m30III-H printer
PS-190 power supply and AC cable
Starter receipt roll and 58 mm paper guide
Setup guide

Interface cables are sold separately unless included in the selected option.

Flexible placement

A compact enclosure supports front or top paper exit and includes a paper near-end sensor.

Connect and charge

USB-C supports wired network tethering to compatible iOS and Android devices. Sync & Charge supplies up to 18 W.

POS hub support

Connect up to two USB POS peripherals. USB-A, USB-B, USB-C and Ethernet are built in; wireless is optional.

Cloud printing

Server Direct Print retrieves jobs from the cloud with an Internet connection. Paper-saving functions reduce unnecessary receipt space.

Print Method

Direct thermal line printing

Print Speed

Up to 300 mm/sec with Epson-approved media

Print Resolution

203 dpi

Print Direction

Vertical and horizontal

Fonts / Column Capacity

Font A: 12 x 24 dots, 48 columns (default); Font B: 10 x 24 dots, 57 columns; Font C: 9 x 17 dots, 64 columns. Kanji A: 24 x 24 dots, 24 columns; Kanji B: 20 x 24 dots, 28 columns (Japanese), 36 columns (Korean).

Character Size

Font A: 1.25 x 3.00 mm; Font B: 1.13 x 3.00 mm; Font C: 0.88 x 2.13 mm; Kanji A: 2.50 x 3.00 mm; Kanji B: 2.26 x 3.00 mm.

Character Set

95 alphanumeric; 18 international; 128 x 43 graphic characters. Japanese: 11,233 JIS X 0213:2004 characters plus 1 special character; Simplified Chinese: 28,553 GB18030-2000 characters; Traditional Chinese: 13,535 Big5 characters; Korean: 8,224 KSC5601 characters.

Barcodes

UPC-A, UPC-E, JAN8/EAN8, JAN13/EAN13, Code39, Code93, Code128, Code 128 Auto, ITF, CODABAR (NW-7), GS1-128, GS1 DataBar

2D Symbols

PDF417, QR Code, MaxiCode, DataMatrix, Aztec Code, Two-Dimensional GS1 DataBar, Composite Symbology

Media Dimensions

80 mm paper: 79.5 +/- 0.5 mm wide, up to 83 mm roll diameter; 58 mm paper: 57.5 +/- 0.5 mm wide, up to 83 mm roll diameter

Paper Thickness

48-80 micrometers

Media Type

Thermal roll paper

Paper Feed Method

Friction feed; supports paper back feed

Paper Width

79.5 mm (3.13 in.) nominal; 57.5 mm (2.26 in.) with the included 58 mm guide

Paper Loading

Drop-in

Maximum Roll Diameter

83 mm (3.27 in.)

Minimum Core Diameter

18 mm (0.71 in.)

Paper Guide

80 mm default; 58 mm spacer included

Auto Cutter

Partial cut (default) or full cut

Interface

All configurations: USB-C (USB 2.0 with up to 18 W device charging), USB-B (USB 2.0 Full Speed), and 10/100Base-T/TX Ethernet. TM-m30III adds one USB-A peripheral port; TM-m30III-H adds two USB-A peripheral ports and one USB-C peripheral port.

Wireless Interface

Wi-Fi + Bluetooth configurations add IEEE 802.11a/b/g/n/ac and Bluetooth 5.0 dual mode. Standard configurations do not include built-in wireless.

Supported Operating Systems

iOS, Android, Windows, Mac OS X, GNU/Linux; use a compatible driver or application for the selected connection

Easy Setting Functions

NFC; Simple AP on Wi-Fi + Bluetooth models. TM-m30III-H also supports QR code setup.

Configuration Utilities

Epson TM Utility (iOS/Android), TM-m30III Utility (Windows; supports TM-m30III and TM-m30III-H), EpsonNet Config, TM Bluetooth Connector

Printer Reliability

17 million printing lines under Epson test conditions

MTBF

360,000 hours under Epson test conditions

MCBF

65 million lines under Epson test conditions

Auto Cutter Lifespan

2.2 million partial cuts; 1.5 million full cuts under Epson test conditions

Paper Exit

Selectable top or front exit

Spill Resistance

IPX2 in front-exit orientation only

NV Bit Image Memory

12 KB maximum

NV Graphics Memory

384 KB maximum

Receive Buffer

4 KB or 45 bytes

Development Tools

Epson ePOS SDK (iOS, Android, JavaScript), TM Print Assistant (iOS/Android), OPOS ADK and OPOS ADK for .NET (Windows), JavaPOS ADK (Windows/Linux)

Printer Drivers

Epson Advanced Printer Driver, TM Virtual Port Driver, Mac Printer Driver, CUPS Driver

Deployment / Monitoring Tools

Epson Deployment Tool, Monitoring Tool, and Firmware Updater

Audible Alert

Optional OT-BZ20 external buzzer

LED Indicators

Power, Error, Paper, Ethernet; Wi-Fi and Bluetooth indicators on built-in wireless models

Sensors

Paper end, cover open, and paper near-end

Cash Drawer Kick

Supported

Power Consumption

Operating: 30.6 W; standby: 1.4 W

Power Supply

Epson PS-190 adapter; included with AC cable in the standard US package

Power Saving

Supported

Operating Temperature

5-45 degrees C (41-113 degrees F)

Operating Humidity

10-90% RH; see the technical reference guide for the temperature/humidity operating range

Acoustic Noise

Approximately 53 dBA under Epson test conditions

Standards / Approvals

FCC Class A; ICES-003 Class A; UL 62368-1 / CSA C22.2 No. 62368-1

Dimensions (W x D x H)

Top exit: 127 x 127 x 130 mm (5.0 x 5.0 x 5.1 in.); front exit: 127 x 128 x 129 mm (5.0 x 5.0 x 5.1 in.)

Weight

Approximately 1,300 g (2.87 lb)

Color Options

Epson White (ENB9) or Epson Black (EBCK), by part number

Cloud Printing

Epson ePOS Print and Server Direct Print; remote cloud printing requires an Internet connection

USB Network Tethering

Up to 20 Mbps for compatible iOS, Android, and Windows devices; actual speed depends on the device, operating system, and network

Smart Device Charging

Sync & Charge: up to 18 W through the USB-C PD port; charging depends on the connected device and cable

USB POS Peripheral Support

TM-m30III: up to 2 devices; TM-m30III-H: up to 4 devices

Paper Saving

TM-M30III sleek 3" Thermal Receipt Printer, USB-A, USB-B, USB-C and Ethernet Interface; Bluetooth and Wifi, White

USB-Hub:

Up to 2 USB peripherals

Interface:

USB-A, USB-B, USB-C, LAN, Bluetooth & WiFi

Color:

White

$319.79

$373.08

C31CK51001

TM-M30III-H sleek 3" Thermal Receipt Printer, USB-A, USB-B, USB-C and Ethernet Interface, White

USB-Hub:

Up to 4 USB peripherals

Interface:

USB-A, USB-B, USB-C & LAN

Color:

White

$408.31

C31CK51002

TM-M30III-H sleek 3" Thermal Receipt Printer, USB-A, USB-B, USB-C and Ethernet Interface, Black

Color:

Black

USB-Hub:

Up to 4 USB peripherals

Interface:

USB-A, USB-B, USB-C & LAN

$408.31
