Epson TM-L90 Plus

Name: Epson TM-L90 Plus
Brand: Epson
Price: 579.79 USD
Availability: InStock

Images may not reflect the actual product

TM-L90 Plus (iOS)

TM-L90 - iOS Compatible Label & Barcode Printer (WiFi, USB) The TM-L90 Plus thermal printer combines receipt and label printing in one compact unit, optimized for use as an iOS-compatible printer for POS system.

• Max Print Width: 3 Inches
• Software: Clover, Toast
• Warranty: 1-Year
• Return Period: 15 Days
• Lifetime Support
• Free Shipping
• Labels: Price labels, barcodes, product labels, receipts, linerless sticky labels, traditional labels, & die-cut labels

Thermal label and receipt printing with flexible installation

The Epson TM-L90 Plus prints labels and receipts from a compact thermal printer. Drop-in roll loading, Windows label-software support and counter or wall installation make it adaptable to different printing locations.

Key Specifications

Print method: Direct Thermal
Print speed: Up to 150 mm/sec in high-speed mode
Paper widths: Liner-backed: 38–80 mm; liner-free widths vary by model
Resolution: 203 dpi
Interfaces / connectivity: USB, serial, parallel, Ethernet or wireless, by configuration
Cutter and reliability: Cutter or peeler varies; cutter rating up to 2 million receipt / 1 million label cuts
Platform support: Epson ESC/POS and supported host drivers/applications
Dimensions and weight: Standard enclosure: 140 × 148 × 203 mm (W × D × H); approx. 1.9 kg
Warranty: 1 year

In the Box

Selected TM-L90 / TM-L90 Plus printer

Package contents and power supply follow the selected option. Choose liner-backed, peeler or liner-free media handling to match the intended labels.

Labels and receipts

Print at 203 dpi with speeds up to 150 mm/sec.

Easy roll loading

Drop-in loading accepts rolls up to 90 mm in diameter. A roll spacer supports narrower paper widths.

Flexible placement

Install the printer on a counter or use the optional wall-hanging bracket.

Peeler configuration available

A version with a label peeler automatically separates labels from their liner. Dual interfaces include built-in USB.

Maximum Roll Diameter

90 mm (3.5 in)

Fonts

9 × 17 and 12 × 24 dots

Character Size

1.13 × 2.13 mm; 1.5 × 3.0 mm; 1.0 × 2.0 mm, W × H

MTBF

360,000 hours under Epson test conditions

Power

24 VDC ± 7%; mean current approximately 1.8 A

Cash Drawer Support

Two drawer-kick drivers

Standards

WEEE and RoHS compliant; FCC Class A, VCCI Class A, CE, Canadian EMI and AS/NZS CISPR22 Class A; UL, CSA and TÜV EN60950

Warranty

1-year limited warranty

In the Box

TM-L90 Plus printer, starter thermal roll and user guide; power supply and AC cable according to configuration

Dimensions

8H x 5.5W x 5.8D in (203 x 140 x 148 mm)

Weight

4.18 lb (1.9 kg)

Color Options

White, Dark Grey

Interface

Built-in USB plus a configuration-specific Connect-It interface: serial RS-232C, parallel IEEE-1284, Ethernet, high-speed USB, powered USB or wireless

Print Speed

Up to 150 mm/s in high-speed mode; 120 mm/s in normal mode

Print Method

Direct Thermal

Print Resolution

203 x 203 dpi (dots per inch)

OPOS Compatible

Yes

Character Set

95 alphanumeric; 18 international; 128 × 17 graphic; traditional/simplified Chinese, Thai and Japanese character sets

Character/Line

48 (using Font A on 3.15" paper)

Graphics Printing

Yes

Receive Buffer

4 KB or 45 bytes receive buffer

Printer Life

Receipt printing: up to 20 million lines with Epson-specified receipt media; thicker media and label use have lower, media-dependent service-life ratings.

MCBF

70,000,000 lines

Auto Cutter Lifespan

Up to 2 million receipt cuts or 1 million label cuts with specified media and cutting conditions; media type, thickness and blade cleaning affect rated life.

Paper Dimensions

80 mm (3.15 in) rolls; use the paper-roll spacer for widths from 38 to 70 mm (1.50–2.76 in)

Barcodes Supported

UPC-A, UPC-E, JAN8 (EAN), Jan13 (EAN), ITF, CODE39, CODE93, CODE128, CODABAR, PDF417, MAXICODE, QRCODE
