DataLogic PowerScan PBT9600

Images may not reflect the actual product
Product Image
small product image0
small product image1

Bluetooth industrial scanning with task-specific optics

The Datalogic PowerScan PBT9600 is a cordless Bluetooth 5.0 scanner for industrial barcode reading. Standard Range covers routine scanning, High Performance handles denser codes and a wider working distance, and Document Capture adds a color sensor for image capture. Auto Range serves near-to-far warehouse scanning, while black DPX models read direct part marks as well as printed labels. Select the optic and base package that fit the application.

Datalogic PowerScan PBT9600 Auto Range industrial scanner seated in its Bluetooth base

Key Specifications

  • Scanner configuration: Cordless Bluetooth area imager
  • Barcode capability: 1D / 2D; DPM on DPX models
  • Reading range: Optic dependent; AR up to 20 m
  • Interfaces / connectivity: Bluetooth 5.0; base-dependent host
  • Durability: 50 drops from 2.5 m at 20°C
  • Environmental sealing: Scanner IP65 and IP67
  • Dimensions: 19.7 × 14.9 × 7.9 cm
  • Weight: 415–445 g
  • Optics choices: SR, HP, DC, AR and DPX
  • Battery capacity: Removable 3350 mAh lithium-ion
  • Warranty: 3 years

The AR maximum of 20 m applies to 100 mil Code 128. Reading ranges vary with code size, quality and light. Bluetooth’s 100 m open-air range is measured with the base station; other hosts and real conditions can differ.

In the Box

  • US USB kits — K10US
    • Selected scanner and removable battery
    • BC9630-BT Bluetooth base and CAB-552 USB cable
    • 8-0935 power supply and 6003-0941 US line cord
  • US RS-232 kits — K20US
    • Selected scanner, battery and BC9630-BT base
    • CAB-548 serial cable, 8-0935 power supply and 6003-0941 US line cord
  • DPX US Ethernet kit — DPXRBK30US
    • DPX scanner, removable battery and BC9680-BT Ethernet base
    • 8-0935 power supply and 6003-0941 US line cord
  • Scanner-only models
    • Selected Bluetooth scanner and removable battery
    • Base, host cable and external power ordered separately

The AR model offered here is scanner only. DPX models are black; the yellow/black hero shows the AR configuration. No display or keypad is included on the offered models.

Direct part marks or long-distance labels

DPX optics combine dedicated illumination, autofocus and Datalogic’s 4D learning system for direct-marked and printed codes. AR autofocus covers a different task: alternating between nearby pick lists and large warehouse labels. Choose the optic for the code surface and working distance.

Wireless charging for repeated industrial use

Inductive charging removes exposed scanner charging contacts and pins that can wear or collect dirt. IP65/IP67 sealing, repeated-drop testing and a trigger tested for ten million actuations support frequent use in demanding work areas.

Scanner Configuration
Cordless Bluetooth handheld area imager; Standard Range, High Performance, Document Capture, Auto Range and DPX direct-part-marking models offered. The offered models have no display or keypad.
Bluetooth Protocol
Bluetooth 5.0 certified wireless technology.
Radio Frequency
2.4 GHz.
Bluetooth Profiles
SPP (Serial Port Profile) and HID (Human Interface Device).
Bluetooth Classes
Class 1, Class 2 and Class 3.
Bluetooth Radio Range
100 m / 328 ft in open air with the base station. Connections to other Bluetooth peripherals and real operating conditions can produce different ranges.
Bluetooth Data Rate
Series datasheet: 3 Mbit/s (2.1 Mbit/s).
Bluetooth Security
Data encryption and scanner authentication.
Battery Type
Removable 3350 mAh lithium-ion battery.
Battery Charging
At 12 VDC external power: 2.5 hours to 95%, 3.2 hours to 100%.
Reads per Charge
Series SR/HP/DC: 80,000 reads; AR and DPX: 80,000+ reads under the manufacturer’s test conditions.
Charging Technology
Inductive wireless charging in a compatible PowerScan 9600 base; removes exposed scanner charging contacts and pins.
Charging Temperature
0 to 40°C nominal; 0 to 35°C ideal.
1D / Linear Codes
All standard linear codes, including GS1 DataBar linear codes.
2D Codes
Aztec, China Han Xin, Data Matrix, MaxiCode, Micro QR, QR and Dot Code.
Postal Codes
SR/HP/DC: Australian Post, British Post, China Post, IMB, Japanese Post, KIX, Planet, Postnet and Royal Mail RM4SCC. AR/DPX: Australian Post, China Post, IMB, Japanese Post, KIX, Planet, Portuguese Post, Postnet, Royal Mail RM4SCC and Swedish Post.
Stacked Codes
EAN/JAN composites; GS1 DataBar composites, Expanded Stacked, Stacked and Stacked Omnidirectional; MacroPDF, MicroPDF417, PDF417 and UPC-A/E composites.
Digital Watermarking
Digimarc barcode support on HP and DC models.
Operating Current
SR/HP/DC and AR cordless models: 480 mA at 3.7 V. DPX cordless models: 552 mA at 4.1 V. Typical charging power less than 15 W; BC96xx cradle operating current 150 mA at 5 V.
Input Voltage
Cordless system: host powered 5 VDC ±5% or 10–30 VDC; external power supply 10–30 VDC ±5%.
Ambient Light
0–100,000 lux.
Drop Resistance
Withstands 50 drops from 2.5 m / 8.2 ft at 20°C; 50 drops from 2.0 m / 6.6 ft at −20°C.
Trigger Resistance
Tested for 10 million actuations.
ESD Protection
20 kV air discharge.
Humidity
0–95%, non-condensing.
Environmental Sealing
Scanner: IP65 and IP67. Cradle: IP65 only on specifically rated models.
Temperature
Cordless models operate from −20 to 50°C / −4 to 122°F. Storage / transport: −40 to 70°C / −40 to 158°F.
Interfaces
Bluetooth scanner links to a compatible host or Bluetooth base. Base host interfaces include USB, RS-232, Ethernet and industrial protocols, depending on the selected base; offered kits use USB, RS-232 or standard Ethernet.
Colors
SR/HP/DC/AR: yellow and black. DPX: black.
Dimensions (H x L x W)
19.7 × 14.9 × 7.9 cm / 7.8 × 5.9 × 3.1 in.
Weight
SR/HP/DC PBT9600: 415 g / 14.6 oz. PBT9600-AR: 445 g / 15.7 oz. PBT9600-DPX: 434.6 g / 15.33 oz.
Image Sensor
1280 × 800 pixels; DC uses a color sensor for document capture.
Light Source
SR/HP/DC: 630–680 nm visible laser aiming and white LED illumination. AR: 650 nm visible laser aiming and red LED illumination. DPX: 650 nm visible laser aiming with white, red and blue LED illumination.
Print Contrast
Minimum: SR/HP/DC and DPX 15%; AR 20%.
Reading Angle
SR/HP/DC and DPX: pitch and skew ±52°, roll 360°. AR: pitch and skew ±60°, roll 360°.
Field of View
SR and HP: 38° horizontal × 24° vertical.
Reading Indicators
SR/HP/DC and DPX: adjustable beeper, Datalogic 3GL Green Spot, dual good-read LEDs and vibration. AR: adjustable beeper, dual good-read LEDs and vibration.
Maximum Resolution
SR/DC: 1D 3 mil, 2D 6 mil. HP: 1D 2.5 mil, 2D 4 mil. AR: 1D 2.5 mil, 2D 5 mil. DPX: 1D 2 mil, 2D 4 mil.
SR Reading Ranges
Code 128: 5 mil 6.4–30.9 cm; 20 mil 4.0–103.7 cm; 40 mil 5.5–175.0 cm. EAN/UPC 13 mil: 4.0–67.5 cm. Data Matrix 10 mil: 6.0–30.0 cm.
HP Reading Ranges
Code 128: 2.5 mil 6.3–11.5 cm; 5 mil 3.8–41.0 cm; 40 mil 5.5–242.9 cm. EAN/UPC 13 mil: 4.0–120.0 cm. PDF417 10 mil: 0.5–46.1 cm. Data Matrix 10 mil: 4.2–32.0 cm.
AR Reading Ranges
Maximum distances: Code 39 3 mil 95 cm, 20 mil 600 cm; EAN/UPC 13 mil 320 cm; Code 128 40 mil 1000 cm, 100 mil 2000 cm; Data Matrix 10 mil 110 cm, 55 mil 650 cm, 100 mil 1000 cm.
Reading Range Conditions
Minimum distance depends on symbol length and scan angle. All distance figures depend on print resolution, contrast and ambient light; long-range maxima require the specified code size.
DPX Reading Ranges
Code 128: 2.5 mil 2.5–9.8 cm; 5 mil 2.5–16.9 cm. EAN/UPC 13 mil: 2.5–22.5 cm. Data Matrix: 5 mil 2.0–10.0 cm; 10 mil 2.0–16.2 cm.
DPX Marking Capability
DPX models read label-printed codes and direct part marks made by laser etching, dot peening, inkjet printing or electrochemical etching; autofocus and the 4D learning system adapt acquisition and decoding settings.
Agency Approvals
Meets necessary safety and regulatory approvals for intended use; consult the Regulatory Addendum or Quick Reference Guide for the certification list.
Environmental Compliance
China RoHS, EU RoHS and REACH.
Laser Classification
CDRH Class II; IEC 60825 Class 2. Do not stare into the beam.
LED Classification
SR/HP/DC: IEC 62471 Exempt. AR and DPX: IEC 62471 Class 1 LED.
Configuration Utility
Datalogic Aladdin available at no charge.
OPOS / JavaPOS
Utilities available at no charge.
Warranty
3-year factory warranty.
PowerScan 9600 Series Datasheet — Rev C (2024)
Download
PowerScan 9600 Auto Range Datasheet — Rev B (2024)
Download
PowerScan 9600 DPX Datasheet — Rev C (2024)
Download

Shop PowerScan PBT9600 Models

PBT9600-SRRBK10US

PowerScan PBT9600, Bluetooth, Standard Range, Removable Battery, USB Kit (Kit includes Scanner PBT9600-SR, Cradle BC9630-BT, Cable CAB-552, Power Supply 8-0935 and Power Cord 6003-0941)

Interface:

Bluetooth Scanner & USB Cradle

Accessories:

Cradle & Power Supplies Included

Scan Engine:

Standard Range

$891.45

PBT9600-DPXRBK30US

PowerScan PBT9600-DPX, Direct Part Marking, Bluetooth, Removable Battery, Ethernet Kit (Kit includes Scanner PBT9600-DPX, cradle BC9680-BT, Power Supply 8-0935 and Power Cord 6003-0941)

Interface:

Bluetooth Scanner & Ethernet Cradle

Accessories:

Cradle & Power Supplies Included

Scan Engine:

Direct Part Marking

$1815.06

PBT9600-DPXRB

PowerScan PBT9600-DPX, Direct Part Marking, Bluetooth, Removable Battery

Interface:

Bluetooth - Scanner Only

Scan Engine:

Direct Part Marking

Accessories:

Scanner Only

$1330.23

PBT9600-DPXRBK20US

PowerScan PBT9600-DPX, Direct Part Marking, Bluetooth, Removable Battery, RS-232 Kit (Kit includes Scanner PBT9600-DPX, cradle BC9630-BT, Cable CAB-548, Power Supply 8-0935 and Power Cord 6003-0941)

Interface:

Bluetooth Scanner & RS-232 Cradle

Accessories:

Cradle & Power Supplies Included

Scan Engine:

Direct Part Marking

$1663.07

PBT9600-DPXRBK10US

PowerScan PBT9600-DPX, Direct Part Marking, Bluetooth, Removable Battery, USB Kit (Kit includes Scanner PBT9600-DPX, Cradle BC9630-BT, Cable CAB-552, Power Supply 8-0935 and Power Cord 6003-0941)

Interface:

Bluetooth Scanner & USB Cradle

Accessories:

Cradle & Power Supplies Included

Scan Engine:

Direct Part Marking

$1668.07

PBT9600-HPRBK10US

PowerScan PBT9600, Bluetooth, High Performance, Removable Battery, USB Kit (Kit includes Scanner PBT9600-HP, Cradle BC9630-BT, Cable CAB-552, Power Supply 8-0935 and Power Cord 6003-0941)

Interface:

Bluetooth Scanner & USB Cradle

Accessories:

Cradle & Power Supplies Included

Scan Engine:

High Performance

$933.69

PBT9600-SRRBK20US

PowerScan PBT9600, Bluetooth, Standard Range, Removable Battery, RS-232 Kit (Kit includes Scanner PBT9600-SR, Cradle BC9630-BT, Cable CAB-548, Power Supply 8-0935 and Power Cord 6003-0941)

Interface:

Bluetooth Scanner & RS-232 Cradle

Accessories:

Cradle & Power Supplies Included

Scan Engine:

Standard Range

$891.45

PBT9600-HPRBK20US

PowerScan PBT9600, Bluetooth, High Performance, Removable Battery, RS-232 Kit (Kit includes Scanner PBT9600-HP, Cradle BC9630-BT, Cable CAB-548, Power Supply 8-0935 and Power Cord 6003-0941)

Interface:

Bluetooth Scanner & RS-232 Cradle

Accessories:

Cradle & Power Supplies Included

Scan Engine:

High Performance

$933.69

PBT9600-DCRBK10US

PowerScan PBT9600, Bluetooth, Document Capture, Removable Battery, USB Kit (Kit includes Scanner PBT9600-DC, Cradle BC9630-BT, Cable CAB-552, Power Supply 8-0935 and Power Cord 6003-0941)

Interface:

Bluetooth Scanner & USB Cradle

Accessories:

Cradle & Power Supplies Included

Scan Engine:

Document Capture

$946.64

PBT9600-SRRB

PowerScan PBT9600, Bluetooth, Standard Range, Removable Battery

Interface:

Bluetooth - Scanner Only

Accessories:

Scanner Only

Scan Engine:

Standard Range

$565.93

PBT9600-HPRB

PowerScan PBT9600, Bluetooth, High Performance, Removable Battery

Interface:

Bluetooth - Scanner Only

Scan Engine:

High Performance

Accessories:

Scanner Only

$608.17

PBT9600-DCRB

PowerScan PBT9600, Bluetooth, Document Capture, Color sensor, Removable Battery

Interface:

Bluetooth - Scanner Only

Scan Engine:

Document Capture

Accessories:

Scanner Only

$621.12

PBT9600-ARRB

Datalogic PowerScan PBT9600-AR, Auto Range, Bluetooth, Removable Battery

Scan Engine:

Auto Range

Interface:

Bluetooth - Scanner Only

Accessories:

Scanner Only

$870.32

Shop PowerScan PBT9600 Accessories

6003-0941

Power Cord, 110V, US

$15.00

BC9630-BT

BC9630 Base Station/Charger, Bluetooth, Multi-Interface (RS-232, USB)

$365.40

BC9631-BT

BC9631 Base Station/Charger, Bluetooth, Multi-Interface (RS-232, USB), IP65

$398.30

RBP-PM96

Battery Pack, Removable, PowerScan 9600

$49.00

MC-P096-E2

Multi Battery Charger, Extension, 2-Slot

$100.10

MC-P096-M2

Multi Battery Charger, Master, 2-Slot (requires the 90ACC0350 power supply)

$134.40

MC-P096-M4

Multi Battery Charger, Master, 4-Slot (requires the 90ACC0350 power supply)

$224.70

CAB-552

Cable CAB-552, USB Type A, Straight, 2m / 6.5 ft, IP67

$23.10

HLS-P080

Holster, Universal, HLS-8000

$47.75

PC-P096

Protective Case/Belt Holster, PowerScan 9600

$19.60

HLD-P096

Holder, Desk/Wall Mount, PowerScan 9600

$16.48

STD-P096

Stand, Hands-free, PowerScan 9600

$27.30

8-0935

Power Supply, Requires Line Cord 6003-0941

$19.00

ZSC2PM9631

Datalogic Ease of Care 3 Year Comprehensive Warranty for PowerScan PM/BT96XXSR. Covers Normal Wear & Tear and Accidental Breakage Coverage. 2-Business-Day Turnaround For Replacement Unit (Excluding Transit). Both Ways Freight Paid By Datalogic. Note: Standard Range Unit Only.

$70.00
