Honeywell PC23d
A compact 2-inch Smart Printer designed for quick setup, flexible placement, and trouble-free light-duty labeling.
Honeywell PC23d Overview
The PC23d brings the PC series' broad feature set to space-constrained counters, laboratories, transportation desks, and retail workstations. One-handed media loading, an intuitive icon interface, and fast direct-thermal output make daily use straightforward.
As a Honeywell Smart Printer, PC23d can run applications inside the printer and connect to supported keyboards, scanners, and other USB peripherals when the workflow needs more than basic label output.
Overview of the Honeywell PC23d and PC43 desktop printer family.
Key Specifications
- Print method: Direct thermal
- Resolution: 203 or 300 dpi, depending on configuration
- Maximum print width: 2.2 in (56 mm)
- Print speed: Up to 8 ips (203 mm/s)
- Media/ribbon handling: 0.6–2.36 in media; rolls up to 5 in; no ribbon required
- Connectivity: USB 2.0 standard; selected configurations add Ethernet, serial, or parallel
- Duty/application fit: Compact desktop labeling and receipt workflows
- Dimensions/weight: 6.5 x 8.5 x 7.0 in; 3.6 lb
- Warranty: One-year depot service
In the Box
Configured printer: Honeywell PC23d printer in the selected interface and regional configuration.
Power supply, power cord, interface cable, media, dispenser, RFID hardware, and other accessories are included only when explicitly named in the selected option.
Designed by Users for Easy Operation
One-Handed Media Loading
Drop-in loading makes resupply quick, while the clear operator interface reduces training and support time.
Flexible Placement
A small footprint plus wall-mount and battery-base options help PC23d fit counters, carts, and other tight spaces.
A Flexible Smart Printer
Up to 8 ips
Fast 2-inch direct-thermal printing keeps up with labels, wristbands, tickets, and receipts.
Inside-the-Printer Applications
Run supported apps locally and attach USB peripherals to streamline specialized workflows.
Upgradeable Connectivity
User-installable interfaces and accessories let the printer adapt after deployment.
Easy Printer Migration
Broad command-language support, including ZSim2, simplifies replacement of other desktop printers.
Shop PC23d Models
PC23DA0010021
PC23d Barcode Printer, Beige with 203 dpi Printing, LCD Display, Adjustable Gap Sensor, Real Time Clock, US Power Cord, USB Interface
DPI:
203 dpi
Interface:
USB
PC23DA0010031
PC23d Barcode Printer, Beige with 300 dpi Printing, LCD Display, Adjustable Gap Sensor, Real Time Clock, US Power Cord, USB Interface
DPI:
300 dpi
Interface:
USB
Shop PC23d Accessories
201-031-230
PC23d Replacement Printhead, 300 dpi Unit
203-183-210
PC23d Ethernet Interface Module
203-184-210
PC23d Label Dispenser Module
203-182-100
USB to Serial Adapter, for Use With PC23 or PC43
203-182-110
USB to Parallel Adapter, for Use With PC23 or PC43
203-183-410
PC43 Ethernet Module
50177263-001
Honeywell Desktop Printer Wi-Fi/Bluetooth Module, US, Compatible with PC23, PC43D, PC43T
SVCPC23-SG3N
Honeywell Edge 3 Year Comprehensive Gold Warranty for PC23D Barcode Printer
