UniTech PA768
Rugged touch computing for warehouse and field work
The Unitech PA768 combines a 6.3-inch high-resolution display, a Snapdragon 6490 processor and integrated 1D/2D barcode scanning for receiving, inventory and mobile field tasks. Standard and Flex Range configurations help match scanning to the job.
Choose Wi-Fi, cellular or restricted USB-only hardware. Listed configurations ship with Android 12 or Android 14, as shown in each model description. The current family supports upgrades through Android 16. Cameras, microphones, GPS, NFC and radios vary by configuration.
Key Specifications
- Operating system / support horizon: Ships with Android 12 or 14 by SKU; family upgrade support through Android 16
- Processor: Snapdragon 6490, octa-core up to 2.7 GHz
- Memory and storage: 6 GB RAM / 64 GB UFS; 128 GB optional
- Display and input: 6.3-inch FHD+ touch display; up to 500 nits
- Scan engine: 1D/2D; Standard and Flex Range offers
- Wireless connectivity: Wi-Fi/Bluetooth or cellular models; restricted USB-only model also available
- Ruggedness and sealing: IP65/IP68; 1.5 m drops, 1.8 m with bumper
- Battery / power: Hot-swappable 5100 mAh; 7700 mAh optional
- Form factor: Touch handheld
- Dimensions: 167 × 75.5 × 17 mm
- Weight: 297 g with bumper and standard battery
- Warranty: 1 year
In the Box
- PA768 terminal in the selected configuration
- Standard battery
- USB Type-C cable
- Power adapter, as specified by the listed offers
- Quick start guide
- Hand strap in the standard manufacturer package
- Bumper where explicitly included in the selected offer
Cradles, extended battery and gun grips are sold separately.
Keep work running during battery changes
The removable 5100 mAh battery supports hot swapping, keeping applications active for up to one minute while the battery is replaced. An optional 7700 mAh battery offers more capacity for demanding shifts.
Use the display indoors and outdoors
The FHD+ display reaches up to 500 nits and supports gloves, a stylus and wet fingers. IP65/IP68 sealing and 1.5 m drop resistance help protect the terminal; the bumper raises the drop rating to 1.8 m.
Shop PA768 Models
PA768-HJNFTMDG
Unitech PA768, Honeywell N5703 Standard-Range 1D/2D, Android 14, 5G / Wi-Fi 6E / Bluetooth, Cameras and HF/NFC; Battery, USB Cable and Power Adapter, Green; TAA Compliant
Shipped OS:
Android 14
Connectivity:
Cellular & WiFi
Standard or Long Range:
Standard Range
PA768-HJ6CTMDG
Unitech PA768, Honeywell Standard-Range 1D/2D, Android 14, Wi-Fi / Bluetooth, GPS, Cameras and HF/NFC; Battery, USB Cable and Power Adapter
Shipped OS:
Android 14
Standard or Long Range:
Standard Range
Connectivity:
WiFi
PA768-WA6FTMDG
Unitech PA768, Honeywell N6803FR Flex Range 1D/2D, Android 12, Wi-Fi / Bluetooth and Cameras; Battery, USB Cable, Power Adapter, Bumpers and Hand Strap; Not TAA Compliant
Shipped OS:
Android 12
Standard or Long Range:
Flex Range
Connectivity:
WiFi
PA768-WA6FRMDG
Unitech PA768, Honeywell N6803FR Flex Range 1D/2D, Android 12, Wi-Fi / Bluetooth and Cameras; USB Cable, Power Adapter, Bumpers and Hand Strap
Shipped OS:
Android 12
Standard or Long Range:
Flex Range
Connectivity:
WiFi
PA768-QANFTMDG
Unitech PA768, Standard-Range 1D/2D, Android 12, Cellular / Wi-Fi / Bluetooth, Cameras and HF RFID; USB Cable, Power Adapter, Bumpers and Hand Strap; TAA Compliant
Shipped OS:
Android 12
Connectivity:
Cellular & WiFi
Standard or Long Range:
Standard Range
PA768-QA00TMDG
Unitech PA768, Standard-Range 1D/2D, Android 12, USB Only; No Radios, Cameras, Microphones, GPS or NFC; USB Cable, Power Adapter, Bumpers and Hand Strap; TAA Compliant
Shipped OS:
Android 12
Standard or Long Range:
Standard Range
Connectivity:
USB Only
Shop PA768 Accessories
1010-601551G
Unitech US AC power cord for compatible cradle and battery-charger power adapters. Power adapter sold separately.
1550-905908G
Unitech USB 3.0 Type-C cable; compatible with EA660, PA768, PA760 and HT730.
5400-900052G
Unitech EA660 / PA768 hand strap with buckle and fixed arm; includes two screws. Individual pack.
383642G
Unitech coiled stylus tether; compatible with EA660 and PA768, and supported HT680 / HT682 / PA550 / PA690 / PA692 / PA968 devices.
5400-900059G
Unitech PA768 bumper kit: top and bottom bumpers with four screws
5500-900102G
PA768 standard gun grip - Before installing, remove bottom bumper, black mylar over pogo pin, and hand strap & bridge from PA768
5500-900103G
RG768 UHF RFID Gun Grip for PA768 with Bumper
1400-900072G
PA768 Extended Battery: 3.85V, 7700mAh Li-ion smart battery w/ packing.
5000-900110G
Unitech PA768 five-slot charging cradle with power supply; AC power cord sold separately
5000-900105G
Unitech PA768 single-slot charging cradle with 5V / 6A power supply; AC power cord sold separately
1400-900069G
PA768 Battery: 3.85V, 5100mAh with packing.
1010-085001G
Unitech 5V/3A QC3 USB power adapter with interchangeable US, EU, UK and AU plugs.
386534G
Unitech 5.5 mm stylus; compatible with EA520, EA660 and PA768.
1010-900073G
Unitech US USB power adapter for compatible EA660, PA768, HT730 and WD200 devices; USB Type-C cable sold separately.
1010-900043G
Unitech 3-pin 5V / 6A power adapter for compatible cradles and battery chargers, including PA768 single-slot cradles. AC power cord sold separately.
1010-900068G
Power Adapter, Input Voltage: 100VAC~240VAC, Output Voltage: 12VDC 5A) (3-pin power cord 1010-601551G is sold separately)
5000-900109G
Unitech PA768 charging cradle for four terminals and four spare batteries; compatible with devices using a bumper or gun grip. Includes 12V/5A power supply. US AC line cord 1010-601551G sold separately.
5000-900111G
Unitech PA768 five-slot charging and Ethernet cradle; compatible with devices using a bumper or gun grip. Includes 12V/5A power supply. US AC line cord 1010-601551G sold separately.
5100-900034G
Unitech PA768 four-slot spare-battery charger. Includes power supply. US AC line cord 1010-601551G and batteries sold separately.
