Custom America P3X
Compact receipt printing with USB, Ethernet and serial connections for retail and hospitality.
The Custom America P3X prints thermal receipts at up to 200 mm per second. Its compact desktop design, full or partial autocutter and 80 mm paper support suit everyday checkout and hospitality stations.
USB, Ethernet and RS-232 interfaces support existing POS connections. Windows and Linux drivers and Custom SDKs for Android and iOS provide integration options; iOS printing uses LAN with an app built for the Custom SDK.
Key Specifications
- Print method: Direct thermal, fixed head.
- Print speed: Up to 200 mm/s.
- Paper widths: 80 mm; 57 mm with the optional reduction kit.
- Resolution: 8 dots/mm (approximately 203 dpi).
- Interfaces / connectivity: USB / Virtual COM, Ethernet, RS-232 and cash drawer.
- Cutter and reliability: Full or partial cut; 1 million cuts and 150 km printhead life.
- Platform support: Windows and Linux drivers; Android and iOS SDK integrations.
- Dimensions and weight: 190 x 142 x 135.5 mm (L x W x H); 1.1 kg device weight.
In the Box
- P3X receipt printer, U.S. configuration 911MH020200733
- AC power supply and U.S. AC power cord
- USB cable
- Quick guide
Receipt paper and Ethernet or serial cables are ordered separately. Printing on 57 mm paper requires the optional paper reduction kit.
Connect to Existing POS Systems
USB, Ethernet and serial interfaces let the same printer fit several wired connection requirements, with Virtual COM available for supported applications.
Choose Full or Partial Receipt Cuts
The autocutter supports both cutting modes and is rated for one million cuts. Desktop or vertical mounting provides placement flexibility.
Shop P3X Models
911MH020200733
P3X 80 mm Thermal Receipt Printer, USB, Ethernet and RS-232, full or partial cutter, black, US power supply and cord, USB cable included.
Shop P3X Accessories
963GE020000071
24 V, 60 W replacement power supply for Custom America P3X; use with the compatible AC power cord.
