UniTech MS851B

Name: UniTech MS851B
Brand: UniTech
Price: 386.58 USD
Availability: InStock

Images may not reflect the actual product

Wireless scanning for warehouse and manufacturing labels

The Unitech MS851B combines a 1D laser scan engine with Bluetooth mobility for warehouse, logistics and manufacturing work. Its bidirectional engine captures up to 104 scans per second and reads a wide range of linear barcodes.

Bluetooth supports transmission up to 100 m in open line of sight. Auto mode buffers scans outside coverage and sends them when the connection returns; batch mode stores scans for later upload. Actual reading distance depends on the barcode size, quality and conditions.

Key Specifications

Scanner configuration: Bluetooth handheld laser scanner
Barcode capability: 1D linear barcodes
Reading range: UPC 13 mil: 4.57–63.50 cm; large Code 39 up to 4.57 m
Interfaces / connectivity: Bluetooth LE 4.2 / 2.1 + EDR; USB cradle in current offer
Durability: 2.1 m drop; trigger rated for 10 million actuations
Environmental sealing: IP42
Dimensions: 87.8 × 71.6 × 177.7 mm
Weight: 213 g without cradle
Warranty: 3 years

In the Box

MS851-SUBB0C-SG package
- MS851B scanner with battery
- Charging cradle
- USB interface cable

Replacement batteries, cables, power adapters and stands are sold separately.

Keep scanning throughout the shift

The rechargeable, replaceable 2850 mAh battery provides more than 30 hours of operation at one scan every five seconds under the manufacturer’s test conditions. LED, beeper and vibration indicators help confirm successful reads.

Built for repeated daily use

IP42 sealing, 2.1 m drop resistance and a trigger rated for 10 million actuations support busy work areas. The cradle provides automatic Bluetooth pairing and switching between trigger and presentation modes.

Scanner configuration

MS851B Bluetooth handheld 1D laser scanner; current MS851-SUBB0C-SG package includes scanner with battery, charging cradle and USB interface cable.

Memory

7.5MB (590,000 barcodes)

Key

Trigger Key

Sensor

1D Laser

Illumination

650 nm visible laser diode

Ambient Light

Sunlight: 8000 Ft Candles (86,111 Lux)

Scan Rate

104 (± 12) scans/sec (bidirectional)

Skew Angle

±40°

Pitch Angle Sensor

±65°

Roll Angle

± 35° from vertical

Optical Resolution

4mil (0.1mm)

Printing Contrast Scale

minimum 20%

Depth of Field

(DOF PCS=80%) -----------------------------------------------Symbology | Density | Near | Far Code 128, 5 mils | 3.55 cm | 17.78 cm Code 39, 5 mils | 3.05 cm | 26.67 cm Code 39, 7.5 mils | 3.04 cm | 41.91 cm Code 128, 10 mils | 3.05 cm | 40.46cm UPC, 13 mils | 4.57 cm | 63.50 cm Code 128, 15 mils | 5.08 cm | 66.04 cm Code 39, 20 mils | 3.56 cm | 116.84 cm Code 39, 55 mils | 8.64 cm | 177.80 cm Code 39, 100 mils | 60.96 cm | 457.20 cm

Radio

Bluetooth LE® V4.2 & Bluetooth® 2.1+EDR, Class 1 Dual mode

Wireless Coverage

100m ( line of sight)

Protocol

Serial Port and HID profiles

Host Interface supported

USB, RS232

Memory Buffer

7MB for batch mode/ 20KB for auto mode

Dimensions (L × W × H)

87.8 L x 71.6 W x 177.7 H (mm)

Weight

213g without cradle

Trigger Switch Life

10 million times

Cradle Dimension

120.6 L x 88.7 W x 86.0 H (mm)

1D Barcodes

Code 39, Full ASCII Code39, Interleave 2 of 5, UPC A/E/E1, MSI, Codabar, Code 11, EAN8/13, Code 93, Code 128, EAN128, Code32, GS1 databar Code, Bookland EAN, Discreate 2 of 5, Chinese 2 of 5, ISBT 128, UCC Coupon Extended Code, Bookland 128

Data Formatting

Prefix, Suffix, Code ID, Reformatting Date

Indicator

LED & Beeper & Vibrator

Battery Type

Rechargeable and replaceable battery pack.

Battery Capacity

2850mAh

Battery Charging time

Manufacturer webpage and Rev.C brochure: 7 hours. Current manual V1.5: less than 6.5 hours; actual charging time depends on conditions.

Operating Time

More than 30 hours; manual V1.5 specifies one scan per 5 seconds. Actual runtime varies with use.

ESD Protection

Functional after 8K Contact and 15K Air

Mechanical Shock

2.1M onto concrete (scanner only)

Operating Temperature

-10°C to 50°C (14°F to 122°F)

Storage Temperature

-40°C to +70°C (-40°F to +158°F)

Relative Humidity

95% non-condensing

IP Rating

IP42

Optional accessories

■ RS232 cable (PN# 1550-905891G) ■ 1-slot charging cradle (PN#5000-900064G) ■ Battery (PN# 1400-900055G) ■ Carrying bag (PN#3210-900025G) ■ power supply for RS232 cable (PN# 1010-900008G) ■ Standard Hands Free Stand (PN#5200-900009G) ■ USB cable with ESD enhanced (PN#1550-905920G) ■ Protective Case (PN#386793G) ■ 5V/2A Adapter(US) (PN#1010-900058G) ■ 5V/2A Adapter with universal plugs (PN#1010-900067G) ■ Desktop/ Wall Mount stand (PN#5200-900011G)

Regulatory Approvals

CE, FCC, BSMI, VCCI, NCC, TELEC, BQB, TAA Compliant

Package contents

■ MS851B Scanner with battery ■ Cradle ■ Interface cable

Warranty

36 months

Warranty terms

This product is warranted against defects in workmanship and materials for a period of three years from the date of shipment. Accessories are warranted for three months to one year. Our different regions have varying warranty terms, and offer extended and comprehensive warranties, so please contact your local representative for more information.

Cradle functions

Automatic Bluetooth pairing and switching between trigger and presentation modes. Rev.C brochure specifies connection with up to three scanners and three-way cable-management slots.

Operating modes

Trigger, presentation, auto / buffer and batch scanning. Auto mode saves out-of-range scans and sends them when coverage returns; batch mode stores scans for later upload.

Charging methods

Current manual V1.5 describes charging through a USB Type-C cable or the charging cradle; a replacement charging cable or adapter is sold separately.

Shop MS851B Models

MS851-SUBB0C-SG

Unitech MS851B 1D Bluetooth laser scanner with battery, USB interface cable and charging cradle; 3-year scanner warranty.

$386.58

Shop MS851B Accessories

1010-900058G

Unitech 5V/2A US USB power adapter for compatible EA520, PA760, MS652 Plus, HT330, RP902, MS838, MS851B and MS852 series devices.

$5.43

1010-900008G

Unitech power adapter for compatible RS232 scanner interface cables, including MS851B / MS852 / MS852 Plus / MS852B. RS232 cable sold separately; USB configurations do not require this adapter.

$16.47
