TSC MH261
Description
Specifications
Download

TSC MH261

Images may not reflect the actual product
Product Image
small product image0
small product image1

6-inch wide-format industrial printers

Wide-format industrial printing without slowing production

The TSC MH261 Series handles shipping, pallet, compliance, and industrial labels up to 6.61 inches wide with fast thermal-transfer or direct-thermal output, a color touchscreen, and network-ready controls.

6.61-inch widthWide logistics and compliance labels
Up to 12 ipsFast 203 dpi production
203 or 300 dpiBalance throughput and detail
450 m ribbonLong thermal-transfer runs

Choose the right configuration

Model family
Resolution
Top speed
Best fit
MH261T
203 dpi
Up to 12 ips
Shipping, pallet, inventory, and general industrial labels
MH361T
300 dpi
Up to 10 ips
Smaller text, denser barcodes, and detailed compliance graphics

Configuration and workflow choices

Broad wired connectivity

USB, serial, parallel, Ethernet, and dual USB Host support workstations, networks, scanners, and keyboards.

Flexible finishing

Optional peel-off, heavy-duty cutter, and internal rewinder kits support batch and apply workflows.

Operator-ready controls

A 4.3-inch color touchscreen, media sensors, and real-time clock keep setup and troubleshooting clear.

What's in the box

Standard package

  • TSC MH261-series printer
  • Quick installation guide
  • Power cord
  • USB interface cable
Printing Method
Thermal transfer and direct thermal
Resolution
203 dpi (MH261T)
300 dpi (MH361T)
Maximum Print Speed
12 ips at 203 dpi
10 ips at 300 dpi
Maximum Print Width
6.61 inches (168 mm)
Maximum Print Length
580 inches at 203 dpi
260 inches at 300 dpi
Media Types
Continuous, die-cut, black mark, fanfold, notch, perforated, tag and care label (outside wound)
Media Width
2 to 6.8 inches (50.8 to 172.7 mm)
Media Thickness
2.36 to 11.02 mil (0.06 to 0.28 mm)
Media Roll Capacity
8.2-inch outside diameter; 1.5- or 3-inch core
Ribbon
Up to 450 m; 1-inch core; 2 to 7 inches wide; ink coated inside or outside
Memory
512 MB Flash; 256 MB SDRAM; microSD expansion up to 32 GB
Interfaces
RS-232, Parallel, USB 2.0, 10/100 Ethernet and two USB Host ports
Optional GPIO and 802.11ac Wi-Fi/Bluetooth
Display and Controls
4.3-inch 480 × 272 color resistive touchscreen; six operation buttons; status LED
Sensors
Adjustable gap and black-mark sensors; head-open, ribbon encoder and ribbon-end sensors
Printer Language
TSPL-EZD; compatible with EPL, ZPL, ZPL II and DPL
Dimensions and Weight
14.05 W × 12.32 H × 20.24 D inches; 39.24 lb
Power
Internal universal power supply; AC 100–240 V, 50–60 Hz
Operating Environment
32 to 104°F (0 to 40°C), 25–85% non-condensing
Storage: -40 to 140°F (-40 to 60°C), 10–90% non-condensing
Warranty
Printer: 2 years
Printhead: 25 km or 12 months
Platen: 50 km or 12 months
MH241/MH261 Series Data Sheet
Download
MH261 Series User Manual
Download

Shop MH261 Models

MH261T-A001-0301

MH261T wide-format industrial label printer, 203 dpi, up to 12 ips, 6.61-inch print width, Wi-Fi-ready.

DPI:

203 dpi

$2344.95

MH361T-A001-0301

MH361T wide-format industrial label printer, 300 dpi, up to 10 ips, 6.61-inch print width, Wi-Fi-ready.

DPI:

300 dpi

$2733.72
