DataLogic Magellan 9900i
Description
Specifications
Download

DataLogic Magellan 9900i

Images may not reflect the actual product
Product Image
small product image0

Bi-optic scanning and weighing for busy checkout lanes

The Datalogic Magellan 9900i reads retail 1D and 2D barcodes through horizontal and vertical scan windows. Low-profile construction and diffused lighting keep the checkout area comfortable. Choose a scanner-only configuration or a scanner/scale with the platter, mounting style and regional weighing configuration your lane requires.

Key Specifications

  • Scanner configuration: Corded bi-optic scanner or scanner/scale
  • Barcode capability: Retail 1D, 2D, stacked and Digimarc codes
  • Reading range: Bi-optic scan zone; optional top-down reader
  • Interfaces / connectivity: USB, RS-232 and Ethernet
  • Durability: Fixed in-counter installation; spill-resistant design
  • Environmental sealing: IP5X optics cavity
  • Dimensions: 29.2 cm wide; 6.9 cm above counter
  • Weight: 6.6–8.2 kg*
  • Scale capacity: Up to 15 kg / 30 lb on scale models
  • Warranty: 1 year

*Weight varies by listed configuration. Medium shelf platter: 39.9 cm long; long flange platter: 50.7 cm. Below-counter depth: 10.2 cm. IP5X applies to the optics cavity, not the entire scanner.

In the Box

  • Magellan 9900i with the selected platter, produce rail, mount and ScaleSentry configuration
  • Listed scanner/scale kits: US power brick and cord
  • USB-A, USB POT or RS-232 cable only when specified by the selected model; -003100 kits require a separate cable
  • Remote scale display only on models explicitly marked with display
  • 99113102000-000101 and -000500: scanner only; power accessories and interface cable sold separately

Top-down readers, customer-facing readers, color cameras and AI hardware are optional. Product images or video may show accessories not included in the selected package. Check the model's US or Canada scale configuration before ordering.

Packages that include a power brick and cord use the US cord. The Canada metric option refers to the scale configuration, not a different power package.

Comfortable scanning from more angles

Four imaging cameras read across the bi-optic scan zone while diffused illumination reduces glare. An optional top-down reader adds a sixth-side view and expands the scan volume by up to 20%.

Help prevent weighing errors

The All-Weighs platter combines horizontal and vertical weighing surfaces for bulky items. On equipped configurations, ScaleSentry detects items extending beyond the weighing surface and alerts the operator with visual and audible feedback.

Model selection glossary
Platter length: The scanning surface length. Choose a size that fits the counter cutout; available sizes vary by model.
Shelf / flange mount: Shelf mount rests on support below the scanner. Flange mount hangs from brackets resting in countertop recesses.
Produce rail: Supports bulky items above the surrounding counter while weighing. Fixed stays raised; flip-up is movable; flush/no rail has no raised rail. A rail does not include a scale.
Scanner only / scanner-scale: Scanner only reads barcodes; scanner-scale also includes a weighing mechanism. A weight display may be separate.
Adaptive-scale-ready: Designed to accept a compatible third-party scale. The scale and integration hardware are separate.
Scale display: The separate weight readout. No display included does not mean no scale is included.
Color camera: Captures item images for supported applications, such as produce recognition. Compatible processing hardware and software are required.
USB Type-A / RS-232: USB or serial connection to the POS. Cable, host connection and POS software must be compatible.
USB POT: Power Off Terminal: requires a compatible powered USB connection. An ordinary USB-A port may not power the scanner.
Power / cable separate: The power supply powers the scanner; the interface cable connects to the POS. Separate means that item is not included.
Regional scale configuration: Weighing units, display language and approved scale configuration must suit the installation. These are separate from the power-cord type.
Single interval / ScaleSentry: Single interval uses one weighing increment across the scale range. ScaleSentry, when equipped, alerts when items extend beyond the weighing surface.
Scanner Configuration
In-counter bi-optic scanner or scanner/scale; scanner-only adaptive-scale-ready configurations also available.
Barcode Decoding
EAN/JAN/UPC, Code 128, EAN/JAN and UPC A/E composites; GS1 DataBar composites, expanded stacked, stacked and stacked omnidirectional; MicroPDF417, PDF417, Aztec, Data Matrix, QR Code, Micro QR and Digimarc. GS1 Digital Link ready.
Imaging System
Four 1 MP global-shutter monochrome cameras; 1280 × 800 pixels; 30 fps.
Illumination
Multiple diffused LEDs, with orientation and wavelength optimized for eye comfort.
Scan Indicators
Visual good-read confirmation for all reading planes. 85 dB speaker with adjustable tone and volume; WAV file support.
Host Interfaces
USB and RS-232. OEM (IBM) USB Plus Power for scanner/scale; separate RS-232 scanner and scale interfaces, RS-232 scanner only, or single-cable RS-232 scanner/scale. Cable and host configuration vary by model.
POS Operating Systems
Windows 10, Linux and Android; OPOS and JavaPOS utilities.
Auxiliary Ports
Two powered USB Type-A host ports; powered RS-232; remote scale display; EAS controller ports for Sensormatic and Interlock.
Ethernet
One Ethernet port standard. Optional seven-port IEEE 1588 Ethernet switch requires a separate external 48 V power supply.
Single-Interval Scale
On equipped models: 0–15 kg / 0–30 lb capacity; minimum increment 0.005 kg / 0.010 lb. Regional unit configuration is model-specific.
Dual-Interval Scale
Optional family configuration. Range 1: 0–6 kg / 0–15 lb, increments 0.002 kg / 0.005 lb. Range 2: 6–15 kg / 15–30 lb, increments 0.005 kg / 0.010 lb. Listed scanner/scale options are single interval.
Adaptive Scale Compatibility
Adaptive-scale-ready models support compatible Bizerba, Mettler Toledo and Digi scales; external scale sold separately.
All-Weighs Platter
Integrated horizontal and vertical scale-platter surfaces expand the active weighing area on scale configurations.
ScaleSentry
Infrared platter detection with configurable audible and visual alerts for items extending beyond the weighing surface; included in the listed configurations.
EAS Support
Configuration-dependent Checkpoint and Nedap antenna support; Sensormatic deactivation controller with SmartSentry technology and good-read/EAS status indicators.
ScanSentry and AI Options
Supports optional AI solutions and camera configurations for checkout monitoring and loss prevention. Cameras, enhanced memory/processing hardware and AI software are not included in every SKU.
Optional Color Cameras
Up to two integrated 1 MP color cameras, 1280 × 800 pixels; Ethernet/USB 3.0 connectivity. Optional network expansion supports additional external cameras. Confirm the required hardware configuration.
Top-Down Reader
Optional 7.0, 9.0 or 12.4 inch top-down reader adds a sixth-side view and increases scan volume by up to 20%; versions with an integrated customer-facing reader are available.
Dimensions
Width: 29.2 cm / 11.5 in. Height above counter: 6.9 cm / 2.7 in. Depth below counter: 10.2 cm / 4.0 in. Length depends on platter and mounting configuration.
Platter Lengths
Short shelf: 35.2 cm / 13.9 in. Medium shelf: 39.9 cm / 15.7 in. Long flange: 50.7 cm / 20.0 in. Consult installation drawings for the exact configuration and counter cutout.
Configuration Weights
Listed medium scanner-only shelf configuration: 6.6 kg. Medium scanner/scale shelf: 7.7 kg; medium scanner/scale flange: 8.0 kg; long scanner/scale shelf: 7.9 kg; long scanner/scale flange: 8.2 kg.
Scanner Input Voltage
12 VDC.
Power Consumption
Nominal operating: 9.3 W. Sleep: 7.3 W.
Power Supplies
Scanner DC brick: 100–240 VAC, 50–60 Hz input. Optional Ethernet-switch brick: 48 VDC output, 100–240 VAC, 50–60 Hz input. Included power accessories depend on kit.
Ambient Light
0–86,080 lux.
Electrostatic Discharge
25 kV air discharge.
Humidity
5–95%, non-condensing.
Operating Temperature
10 to 40 °C / 50 to 104 °F.
Storage and Transport Temperature
−40 to 70 °C / −40 to 158 °F.
Environmental Protection
IP5X dust-resistant optics cavity. Spill-proof design under Datalogic test method MS-0006-13-0004. No whole-device IP54 or IP52 rating is specified.
Agency Approvals
Meets applicable safety and regulatory approvals for its intended use; consult the manufacturer regulatory and installation documentation for the exact configuration.
Environmental Compliance
China RoHS, EU RoHS and REACH EC 1907/2006.
Configuration Utility
Datalogic Aladdin supports configuration, firmware updates and advanced data formatting.
Software Development
Datalogic tools and APIs support POS integration and optional AI applications; required camera and processing hardware is configuration-dependent.
Remote Management
Diagnostic reporting through WMI with OPOS/JavaPOS and MBeans with JavaPOS. Host download supports IBM Director, Wavelink Avalanche and other ERP management solutions.
US Scanner/Scale Packages
99211212000-003100, 99222212000-003100 and 99212212000-003100 include US power brick/cord but no interface cable. 99211212000-003520 and 99221212000-003520 include USB Type-A external-power cable. 99222212000-003530 includes USB POT cable.
Scale Display Packages
99211211000-013310 and 99222211000-013310: US single-interval English scale configuration with display, US power brick/cord and RS-232 cable. 99222713000-023310: Canada single-interval metric scale configuration with display, US power brick/cord and RS-232 cable.
Scanner-Only Packages
99113102000-000101 and 99113102000-000500: adaptive-scale-ready scanner, medium platter, flip-up produce rail, shelf mount and ScaleSentry. Power accessories, interface cable and external scale sold separately. Current manufacturer catalog does not distinguish their factory host setting.
Warranty
1-year standard factory warranty.
Magellan 9600i / 9900i Brochure and Technical Specifications
Download
Magellan 9900i Product Reference Guide
Download
Magellan 9900i Quick Reference Guide
Download
Magellan 9900i Top-Down Reader Installation Guide
Download
Datalogic USB-COM Driver 7.1.5
Download

Shop Magellan 9900i Models

99221212000-003520

Datalogic Magellan 9900i Scanner/Scale, Long Platter/Fixed Produce Rail/Shelf Mount with ScaleSentry, US/Single Interval/English Config, US Power Brick/Cord, USB Type-A External-Power Cable

Produce Rail:

Fixed rail

Platter Length:

Long

Scale Display:

Not included

Power Package:

Power supply and cord

Configuration:

Scanner/scale

Mount Type:

Shelf mount

Scale Region / Units:

US: lb, single interval

Interface:

USB Type-A external-power cable

$2072.36

99222211000-013310

Datalogic Magellan 9900i Scanner/Scale, Long Platter/Fixed Produce Rail/Flange Mount with ScaleSentry, US/Single Interval/English Config with Display, US Power Brick/Cord, RS-232 Cable

Produce Rail:

Fixed rail

Mount Type:

Flange mount

Scale Display:

Included

Platter Length:

Long

Power Package:

Power supply and cord

Interface:

RS-232 cable

Configuration:

Scanner/scale

Scale Region / Units:

US: lb, single interval

$2170.90

99211211000-013310

Datalogic Magellan 9900i Scanner/Scale, Medium Platter/Fixed Produce Rail/Shelf Mount with ScaleSentry, US/Single Interval/English Config with Display, US Power Brick/Cord, RS-232 Cable

Produce Rail:

Fixed rail

Scale Display:

Included

Platter Length:

Medium

Power Package:

Power supply and cord

Interface:

RS-232 cable

Configuration:

Scanner/scale

Mount Type:

Shelf mount

Scale Region / Units:

US: lb, single interval

$2170.90

99211212000-003100

Datalogic Magellan 9900i Scanner/Scale, Medium Platter/Fixed Produce Rail/Shelf Mount with ScaleSentry, US/Single Interval/English Config, US Power Brick/Cord (Cable Sold Separately)

Produce Rail:

Fixed rail

Platter Length:

Medium

Scale Display:

Not included

Power Package:

Power supply and cord

Configuration:

Scanner/scale

Mount Type:

Shelf mount

Scale Region / Units:

US: lb, single interval

Interface:

USB / RS-232 (cable separate)

$2052.29

99222212000-003100

Datalogic Magellan 9900i Scanner/Scale, Long Platter/Fixed Produce Rail/Flange Mount with ScaleSentry, US/Single Interval/English Config, US Power Brick/Cord (Cable Sold Separately)

Produce Rail:

Fixed rail

Mount Type:

Flange mount

Platter Length:

Long

Scale Display:

Not included

Power Package:

Power supply and cord

Configuration:

Scanner/scale

Scale Region / Units:

US: lb, single interval

Interface:

USB / RS-232 (cable separate)

$2052.29

99212212000-003100

Datalogic Magellan 9900i Scanner/Scale, Medium Platter/Fixed Produce Rail/Flange Mount with ScaleSentry, US/Single Interval/English Config, US Power Brick/Cord (Cable Sold Separately)

Produce Rail:

Fixed rail

Mount Type:

Flange mount

Platter Length:

Medium

Scale Display:

Not included

Power Package:

Power supply and cord

Configuration:

Scanner/scale

Scale Region / Units:

US: lb, single interval

Interface:

USB / RS-232 (cable separate)

$2052.29

99222713000-023310

Datalogic Magellan 9900i Scanner/Scale, Long Platter/Fixed Produce Rail/Flange Mount with ScaleSentry, Canada/Single Interval/Metric Config with Display, US Power Brick/Cord, RS-232 Cable

Scale Region / Units:

Canada: kg, single interval

Produce Rail:

Fixed rail

Mount Type:

Flange mount

Scale Display:

Included

Platter Length:

Long

Power Package:

Power supply and cord

Interface:

RS-232 cable

Configuration:

Scanner/scale

$2170.90

99211212000-003520

Datalogic Magellan 9900i Scanner/Scale, Medium Platter/Fixed Produce Rail/Shelf Mount with ScaleSentry, US/Single Interval/English Config, US Power Brick/Cord, USB Type-A External-Power Cable

Produce Rail:

Fixed rail

Platter Length:

Medium

Scale Display:

Not included

Power Package:

Power supply and cord

Configuration:

Scanner/scale

Mount Type:

Shelf mount

Scale Region / Units:

US: lb, single interval

Interface:

USB Type-A external-power cable

$2072.36

99222212000-003530

Datalogic Magellan 9900i Scanner/Scale, Long Platter/Fixed Produce Rail/Flange Mount with ScaleSentry, US/Single Interval/English Config, US Power Brick/Cord, USB POT Cable

Produce Rail:

Fixed rail

Mount Type:

Flange mount

Platter Length:

Long

Scale Display:

Not included

Power Package:

Power supply and cord

Configuration:

Scanner/scale

Scale Region / Units:

US: lb, single interval

Interface:

USB POT cable

$2085.35

99113102000-000101

Datalogic Magellan 9900i Scanner Only, Adaptive Scale Ready, Medium Platter/Flip-up Produce Rail/Shelf Mount with ScaleSentry (Power Accessories and Cable Sold Separately)

Configuration:

Adaptive-scale-ready scanner

Produce Rail:

Flip-up rail

Platter Length:

Medium

Scale Region / Units:

No integrated scale

Scale Display:

Not included

Mount Type:

Shelf mount

Power Package:

Sold separately

Interface:

USB / RS-232 (cable separate)

$1483.53

99113102000-000500

Datalogic Magellan 9900i Scanner Only, Adaptive Scale Ready, Medium Platter/Flip-up Produce Rail/Shelf Mount with ScaleSentry (Power Accessories and Cable Sold Separately)

Configuration:

Adaptive-scale-ready scanner

Produce Rail:

Flip-up rail

Platter Length:

Medium

Scale Region / Units:

No integrated scale

Scale Display:

Not included

Mount Type:

Shelf mount

Power Package:

Sold separately

Interface:

USB / RS-232 (cable separate)

$1483.53
