MicroTouch Mach Digital Signage
Large-format 4K commercial displays with touch and non-touch choices for signage, collaboration and presentation.
MicroTouch Mach Digital Signage gives buyers a common 4K platform across 49-, 55- and 65-inch screen sizes. Current POSGuys configurations include M1 interactive touch displays and newer M2 non-touch models.
Choose an M1 model when the installation needs direct PCAP interaction, or an M2 DSN model when high-resolution content display is the priority.
Key Specifications
- Product type / application: Commercial 4K signage displays for digital signage, collaboration, wayfinding and presentations
- Display / resolution: 49-, 55- or 65-inch; 3840 x 2160
- Touch input: Projected-capacitive touch on M1 DS models; non-touch on M2 DSN models
- Host compatibility: USB touch on M1 models with standard HDMI, DisplayPort and VGA video hosts
- Interfaces / connectivity: 2 x HDMI, DisplayPort, VGA, RS-232 and RJ45 Ethernet on current M2 models; touch configurations add USB-HID touch and a USB service/media port
- Power: Integrated 100–240VAC, 50/60Hz input; 49-inch touch is 135W typical, 55-inch touch is 175W typical, 65-inch touch is 255W typical, and current non-touch models are rated to 150W maximum
- Durability / environment: Commercial indoor display; operating limits vary by model
- Mounting / form factor: VESA mounting; mount sold separately
- Dimensions / weight: M2-490DS-A1: 1139.2 x 669.4 x 77.7 mm, 26 kg; M2-550DS-A1: 1275 x 745.8 x 77.7 mm, 30 kg; M2-650DS-A1: 1493.2 x 868.24 x 89.9 mm, 42 kg; M2-490DSN-A1: 1098.5 x 628.7 x 74.5 mm, 18 kg; M2-550DSN-A1: 1234.3 x 705.1 x 74.5 mm, 21.5 kg
- Warranty: 3 years
In the Box
- M2 touch configurations: Display, regional AC power cord, HDMI cable, USB touch cable, remote control, IR extender, passive pens and batteries
- M2 non-touch configurations: Display, regional AC power cord, HDMI cable, remote control and IR extender
- Mounting: Wall mount or floor stand is selected separately for the installation
Select touch or non-touch
Pay for interaction only where it adds value
M1 DS configurations support touch-driven wayfinding and collaboration. M2 DSN models remove the touch layer for presentation and signage deployments that only need a high-quality 4K screen.
Keep content consistent
One 4K canvas across three sizes
All active screen sizes use a 3840 x 2160 canvas, making it easier to reuse high-resolution content across different viewing distances and installation footprints.
Shop Mach Digital Signage Models
M2-490DSN-A1
MicroTouch M2-490DSN-A1 49" non-touch 4K digital signage display, 3840 x 2160, 2 HDMI, DisplayPort, VGA, RS-232 and RJ45
Display Size:
49"
Touch Display:
No Touch
M2-550DSN-A1
MicroTouch M2-550DSN-A1 55" non-touch 4K digital signage display, 3840 x 2160, 2 HDMI, DisplayPort, VGA, RS-232 and RJ45
Display Size:
55"
Touch Display:
No Touch
M2-490DS-A1
MicroTouch M2-490DS-A1 49" optically bonded PCAP digital signage monitor, 3840 x 2160, over 55 touch points, 450-nit touch brightness, 2 HDMI, DisplayPort and VGA, IP65 front, TAA
Display Size:
49"
Touch Display:
With Touch
M2-550DS-A1
MicroTouch M2-550DS-A1 55" optically bonded PCAP digital signage monitor, 3840 x 2160, 55 touch points, 450-nit touch brightness, 2 HDMI, DisplayPort and VGA, IP65 front, TAA
Display Size:
55"
Touch Display:
With Touch
M2-650DS-A1
MicroTouch M2-650DS-A1 65" optically bonded PCAP digital signage monitor, 3840 x 2160, 55 touch points, 450-nit touch brightness, 2 HDMI, DisplayPort and VGA, IP65 front, TAA
Display Size:
65"
Touch Display:
With Touch
