MicroTouch M1-MP-AA2

Images may not reflect the actual product
Product Image
small product image0
small product image1
small product image2
small product image3
small product image4

A compact commercial Android player for adding apps, web content and interactive media to displays.

The MicroTouch M1-MP-AA2 turns touchscreen monitors and static signage displays into commercial Android systems. It can run video and audio content, interactive HTML pages and Android apps for digital signage, kiosks and other content-driven installations.

MediaTek Genio 700 processing, 8GB memory and 64GB eMMC storage are paired with HDMI, USB, Gigabit Ethernet, Wi-Fi and Bluetooth connectivity in a compact metal enclosure.

MicroTouch M1-MP-AA2 Android media player

Key Specifications

  • Product type / application: Compact commercial Android media player for signage and interactive display deployments
  • Core performance: MediaTek Genio 700 processor with Mali-G57 MC3 graphics
  • Supported workload: Android media playback, connected signage and peripheral-driven applications
  • Platform / compatibility: Android 13 GMS; upgradeable to Android 15 GMS
  • Interfaces / connectivity: HDMI, three USB-C, two USB 3.0 Type-A, Gigabit Ethernet, Wi-Fi 6 and Bluetooth 5.2
  • Power: 12V, 60W external adapter
  • Durability / environment: Die-cast / SECC metal housing; 0°C to 40°C operating range
  • Deployment / form factor: Compact external player with Mini PCIe expansion slot
  • Dimensions / weight: 146 x 32.8 x 160 mm; 0.73 kg
  • Warranty: 3 years

In the Box

  • M1-MP-AA2 media player and 12V 60W external power adapter

Display, mount, input devices and application software are selected separately.

Add Android to a display

Content playback plus interactive applications

Use the player for scheduled media, web-based experiences or Android applications without replacing an existing compatible screen.

Connect it to the installation

Wired and wireless options in one compact box

HDMI carries video to the display, while Gigabit Ethernet, Wi-Fi, Bluetooth and multiple USB ports support network access and common peripherals.

Processor
MediaTek Genio 700 (MT8390)
GPU
Mali-G57 MC3
System Memory
8GB
Storage Device
64GB eMMC
Wi-Fi & Bluetooth
802.11 a/b/g/n/ac/ax; Bluetooth 5.2 with BLE
USB Port
Three USB-C ports and two USB 3.0 Type-A ports; USB-C functions include PD output and OTG support
LAN Port
1 x RJ45 Gigabit Ethernet
Video Port
1 x HDMI
Audio Port
1 x line output
Expansion Slot
1 x Mini PCIe slot
Power Input
12V 60W external power adapter
GPIO
1 x GPIO
Operating System
Android 13 GMS; upgradeable to Android 15 GMS
Material
Die-cast and SECC metal
Housing Color
Black
Dimensions (W x H x D)
146 x 32.8 x 160 mm
Net Weight
0.73 kg
Gross Weight
2.45 kg
Carton (W x H x D)
250 x 160 x 290 mm
Operating Temperature
0°C to 40°C; 20% to 80% RH, non-condensing
Storage Temperature
-20°C to 60°C; 10% to 90% RH, non-condensing
MicroTouch All-in-One Series Overview Flyer
Download
M1-MP-AA2 Data Sheet (Jun 2026)
Download
M1-MP-AA2 User Manual (Aug 2026)
Download

Shop M1-MP-AA2 Models

M1-MP-AA2

MicroTouch M1-MP-AA2 Android media player, MediaTek 8390, 8 GB memory, 64 GB eMMC storage, HDMI, USB-A, USB-C, Gigabit Ethernet, Wi-Fi and Bluetooth; 3-year warranty

$698.26
