Zebra DS3678

Name: Zebra DS3678
Brand: Zebra
Price: 786.97 USD
Availability: InStock

Images may not reflect the actual product

Scan Past Any Challenge with Unstoppable Barcode Scanners

The cordless DS3678 combines Zebra’s ultra-rugged DS3600 platform with Bluetooth mobility, PowerPrecision+ battery visibility and rugged cradle options. Standard-range, high-density and high-performance engines support fast 1D/2D capture across manufacturing floors, warehouses, yards and cold environments.

POSGuys compares Zebra 3600 Series performance across scan engines and barcode conditions.

Key Specifications

Scanner configuration: Cordless ultra-rugged handheld area imager; SR, HP and HD engine options

Barcode capability: 1D and 2D barcodes, including QR Code and PDF417

Reading range: Varies by selected standard-range, high-performance or high-density engine

Interfaces / connectivity: Bluetooth 4.0 Low Energy Class 1 with at least 300 ft./100 m line-of-sight range; cradle interfaces vary by configuration

Durability: Multiple 10 ft./3 m drops at room temperature, multiple 8 ft./2.4 m drops across operating temperature and 7,500 tumbles from 3.3 ft./1 m

Environmental sealing: IP65 and IP68 scanner; IP65 forklift cradle

Dimensions and weight: 7.3 x 3.0 x 5.6 in./18.5 x 7.7 x 14.3 cm; approximately 14.34 to 14.50 oz./407 to 411 g with battery, depending on engine

Warranty: Scanner and cradle: 36 months; battery: 12 months

Battery: PowerPrecision+ 3100 mAh battery; scan capacity varies by engine

Feedback: Direct Decode Indicator, LEDs, beeper and vibration

In the Box

Selected DS3678-SR, DS3678-HP or DS3678-HD cordless scanner with PowerPrecision+ battery

Scanner-only configurations: scanner and battery; cradle, interface cable and power components sold separately

USB cradle kits: selected scanner, USB cable, standard cradle and power supply as named in the option

Configuration note: Any additional cable, cradle, charger, power or mounting accessories are sold separately unless the selected option explicitly includes them.

Benefits of the DS3600 Series

Superior Performance

Advanced imaging captures damaged, dirty and poorly printed 1D/2D barcodes quickly, helping keep receiving, production and shipping moving.

Cordless, Ultra-rugged Design

IP65/IP68 sealing, repeated 10 ft drops and Bluetooth freedom prepare the DS3678 for harsh sites where cables restrict movement.

Zebra DNA for Scanners - Set Up. Secure. Manage. Optimize.

123Scan

Program one scanner or stage many devices with a guided utility and printable configuration barcodes.

Virtual Tether

Alert workers when a scanner moves beyond its base, needs charging, is misplaced or stays out of its cradle too long.

Remote Management (SMS/WMI)

Configure and maintain deployed scanners remotely with Scanner Management Service or Windows Management Instrumentation.

Dimensions

7.3 in. H x 3.0 in. W x 5.6 in. D (18.5 cm H x 7.7 cm W x 14.3 cm D)

Weight

Varies by scan engine: approximately 14.34 to 14.50 oz. (407 to 411 g) with battery

Input Voltage Range

Host powered: 4.5 VDC min., 5.5 VDC max.; External power supply: 11.4 VDC min., 12.6 VDC max.

Color

Industrial Green

Supported Host Interfaces

Cradle: USB, RS-232 and Keyboard Wedge; Industrial Ethernet: EtherNet/IP, PROFINET, Modbus TCP and standard TCP/IP

Battery

PowerPrecision+ 3100 mAh Li-Ion rechargeable battery

User Indicators

Direct Decode Indicator; LEDs; beeper; vibration

Scans per Full Charge

100,000+ (configuration and use dependent)

Aiming and Illumination

SR: orange LED aiming dot with red illumination; HD/HP: 655 nm laser aiming pattern with white illumination

Imager Field of View

Varies by selected SR, HD or HP scan engine

Image Sensor

1,280 x 960 pixels

Minimum Print Contrast

15% minimum reflective difference

Skew/Pitch/Roll

Skew: ±60°; Pitch: ±60°; Roll: ±360°

Decode Capabilities

1D and 2D symbologies including PDF417, Data Matrix, MaxiCode, QR Code and postal codes; HP also supports OCR

Operating Temperature

-4°F to 122°F (-20°C to 50°C)

Storage Temperature

-40°F to 158°F (-40°C to 70°C)

Humidity

5% to 95% noncondensing

Drop Specification

Multiple 10 ft./3.0 m drops to concrete at room temperature; multiple 8 ft./2.4 m drops across -20°C to 50°C

Tumble Specification

7,500 tumbles from 3.3 ft./1.0 m

Sealing

Scanner: IP65 and IP68 per applicable IEC sealing specifications; FLB cradle: IP65

ESD

Per EN61000-4-2: ±25 kV air discharge, ±10 kV direct discharge and ±10 kV indirect discharge

Ambient Light Immunity

0 to 10,037 foot-candles/0 to 108,000 lux (direct sunlight)

123Scan

Programs scanner parameters, upgrades firmware, provides scanned barcode data and prints reports

Scanner SDK

Provides scanner application documentation, drivers, test utilities and sample source code

Scanner Management Service (SMS)

Remotely manages Zebra scanners and queries asset information

Network Connect

Connects 3600 Series scanners to Industrial Ethernet networks without added conversion equipment

Bluetooth Radio

Bluetooth Class 1, Version 4.0 (LE), Serial Port Profile (SPP) and HID profiles

Data Rate

Classic Bluetooth: 3 Mbit/s (2.1 Mbit/s); Low Energy: 1 Mbit/s (0.27 Mbit/s)

Radio Range

Direct line of sight in open air: Class 1 minimum 300 ft./100 m; Class 2 minimum 30 ft./10 m

Environmental

RoHS EN 50581:2012

Electrical Safety

EU: EN 60950-1; International: IEC 60950-1; US/Canada: UL 60950-1 and CAN/CSA-C22.2 No. 60950-1-07

Laser/LED Safety

International LED safety IEC 62471/EN 62471; recognized laser components for HD/HP configurations

EMI/RFI

Class B emissions; IT and heavy-industrial immunity; FCC Part 15/ICES-003 Class B

SR Decode Ranges (Typical)

Code 128 5 mil: 1.3-6.7 in.; Code 39 5 mil: 0.5-12.0 in.; 100% UPC 13 mil: 0.3-24.0 in.; Data Matrix 10 mil: 1.4-8.6 in.

HD Decode Ranges (Typical)

Code 128 5 mil: 0.9-7.0 in.; Code 39 3 mil: 1.3-4.7 in.; PDF417 5 mil: 2.0-6.0 in.; Data Matrix 10 mil: 1.0-9.0 in.

HP Decode Ranges (Typical)
