MicroTouch Digital Signage Series
Large-format PCAP displays for collaborative applications, wayfinding and custom branded kiosks.
MicroTouch Digital Signage touch displays bring responsive multi-touch interaction to large-format installations. The active POSGuys range includes 31.5-inch Full HD models and a 43-inch 4K model for more detailed content.
Use the series for wayfinding, collaboration, self-service and branded interactive experiences where a slim profile and broad viewing angles matter.
Key Specifications
- Product type / application: Large-format commercial PCAP displays for interactive signage, wayfinding, collaboration and kiosks
- Display / resolution:
- 31.5-inch: 1920 x 1080
- 43-inch B2: 3840 x 2160
- Touch input:
- 31.5-inch: Projected capacitive, 10 points
- 43-inch B2: Projected capacitive, 40 points
- Interfaces / connectivity:
- 31.5-inch: VGA, DVI-D and HDMI
- 43-inch B2: HDMI, DVI-I and DisplayPort
- Host compatibility: USB-HID touch with standard commercial video inputs
- Power: Integrated 100-240VAC, 50/60Hz AC input on all active models
- Durability / environment:
- All active models: Front-panel IP65 protection; 0°C to 40°C operation
- DS-320P-A1/A2: IK07
- DS-430P-B2: IK08
- Mounting / form factor:
- DS-320P-A1/A2: 400 x 200 mm VESA
- DS-430P-B2: 400 x 400 mm VESA
- Mount sold separately
- Dimensions / weight:
- DS-320P-A1/A2: 781.5 x 476.6 x 66.8 mm / 15.0 kg
- DS-430P-B2: 983.2 x 571.4 x 82.3 mm / 19.5 kg
- Warranty: 3 years
In the Box
- DS-320P-A1/A2:
- LCD touch monitor
- power cord
- DVI cable
- USB A-to-B cable
- HDMI cable
- VGA cable
- two nuts
- four M5 x 8 mm screws
- two washers
- DS-430P-B2:
- LCD touch monitor
- HDMI cable
- I/O cover
- USB A-to-B cable
- audio cable
- power cable
Choose Full HD or 4K
Content detail across screen sizes
The 31.5-inch models are suited to Full HD interactive content, while DS-430P-B2 provides 4K resolution and 40 touch points for larger, more detailed collaborative experiences.
Built for engagement
Wide viewing angles and flexible source connections
Broad 178-degree viewing and multiple digital video inputs make the displays easier to integrate into public-facing signage, wayfinding and custom kiosk systems.
Shop Digital Signage Series Models
DS-320P-A2
MicroTouch DS-320P-A2 31.5-inch PCAP digital signage monitor, 1920 x 1080, 10-point touch, 400 nits, VGA, DVI-D and HDMI; mount sold separately
Resolution:
1920 x 1080
Display Size:
31.5"
DS-320P-A1
MicroTouch DS-320P-A1 31.5-inch PCAP digital signage monitor, 1920 x 1080, 10-point touch, 360-nit touch brightness, IP65 front, VGA, DVI-D and HDMI
Resolution:
1920 x 1080
Display Size:
31.5"
DS-430P-B2
MicroTouch DS-430P-B2 43-inch PCAP digital signage monitor, 3840 x 2160, 40-point touch, 450-nit touch brightness, IP65 front, HDMI, DVI-I and DisplayPort; mount sold separately
Resolution:
3840 x 2160
Display Size:
43"
