Custom America D4
Description
Specifications
Download

Custom America D4

Images may not reflect the actual product
Product Image
small product image0
small product image1
small product image2

A compact 4-inch desktop printer for flexible direct-thermal and thermal-transfer labeling.

The Custom America D4 is a compact desktop label printer for retail, logistics, manufacturing, and other workflows that need dependable 4-inch labels.

Choose USB or USB/Ethernet for the connection that fits your deployment. The D4 supports direct-thermal media for short-term labels and thermal-transfer applications for more durable prints.

Key Specifications

  • Print method: Direct thermal or thermal transfer.
  • Resolution: 203 dpi.
  • Maximum print width: 104 mm.
  • Print speed: Up to 5 ips.
  • Media and ribbon handling: 15–110 mm media; continuous, die-cut, tag, fan-fold, and black-mark media; wax, wax/resin, or resin ribbon up to 100 m.
  • Connectivity: USB; 10/100 Ethernet by configuration.
  • Duty / application fit: Four-inch desktop labels for retail, logistics, manufacturing, and similar workflows.
  • Dimensions and weight: 263 × 200 × 188 mm; 2 kg.
  • Warranty: 1 year

In the Box

  • Custom America D4 label printer in the selected interface configuration
  • Switching power adapter

Peeler and cutter options are configuration-dependent.

Flexible Media Handling

One platform for changing label needs

Use direct-thermal media for short-term labels or thermal-transfer ribbon for applications that need longer-lasting prints.

Deployment-Ready Connectivity

Match the interface to your workflow

USB supports straightforward local installation, while the Ethernet configuration supports networked printer placement.

Printing Method
Direct thermal or thermal transfer
Print Resolution
203 dpi
Max. Print Speed
5 ips
Print Width
104 mm
Emulations
PEPL, PDPL, PZPL
Memory
64 MB SDRAM; 128 MB flash
Interfaces
USB; Ethernet 10/100 Mbps (option/configuration-dependent)
Sensors
Moveable reflective sensor; cover-open sensor; ribbon sensor
Media Types
Continuous, die-cut, tag, fan-fold black mark
Media Width
15–110 mm
Media Thickness
0.06–0.20 mm
Maximum Roll Diameter
127 mm; 25.4 mm core
Ribbon Support
Wax, wax/resin, or resin; up to 100 m; 25.4–110 mm width; 39 mm OD; 12.7 mm ID
Dimensions
263 × 200 × 188 mm (L × W × H)
Weight
2 kg
Power
100–240 V, 1.8 A, 50–60 Hz input; 24 V, 2.5 A output
Operating / Storage Environment
Operation 5–45 °C; storage −20–50 °C; humidity operation 10–90% non-condensing, storage 5–95% non-condensing
Warranty
1 year
Custom D4 User Manual
Download
Custom D4 Driver Zip Folder
Download
Custom D4 Setup Utility
Download
Spec Sheet
Download

Shop D4 Models

911MK010100233

D4 4-inch Label Printer, USB, black, direct thermal and thermal transfer.

Interface:

USB

$261.17

911MK010500J33

D4 4-inch Label Printer, USB and Ethernet, black, direct thermal and thermal transfer.

Interface:

USB and Ethernet

$274.06

Outlet Items

Custom D4
Outlet thumbnail 1Outlet thumbnail 2Outlet thumbnail 3

Custom D4

Custom D4 Label Printer (Renewed, Reconditioned). USB. Black. (911MK010100233) CID: 4574

Item Number: 911MK010100233

1 Reconditioned Available

CID: 4574

$200.00

Shop D4 Accessories

976MK010000001

Custom America D4 Cutter Module Add-On

$98.04

976MK010000002

Custom America D4 Peeler Module Add-On

$60.25

105903-053-3PACK

4-inch Ribbon Take-Up Core for 4-inch Thermal Transfer Printers, 0.5-inch OD (3-Pack)

$18.00
