Honeywell CT47

Name: Honeywell CT47
Brand: Honeywell
Price: 2774.2 USD
Availability: InStock

Images may not reflect the actual product

Ultra-rugged 5.5-inch mobile computing with Wi-Fi 6E, optional 5G, and near-to-far barcode capture.

Brand update: The CT47 is now a Brady product, formerly sold as the Honeywell CT47.

The Honeywell CT47 is a full-touch mobile computer for warehouse, logistics, manufacturing, and field-service teams that need dependable scanning and fast wireless communication. Built on Honeywell's Mobility Edge platform, it combines enterprise Android, a 2.7 GHz Qualcomm processor, Wi-Fi 6E, and optional 5G connectivity.

Current POSGuys configurations offer 6 GB or 8 GB RAM, 128 GB flash storage, and Standard Range, FlexRange, or FlexRange XLR scanning. Select the memory, scan range, and cellular combination that matches the workflow.

Key Specifications

Operating system / support horizon: Android on Honeywell Mobility Edge; released with Android 12 and guaranteed through Android 15.
Processor: Qualcomm QCS6490/QCM6490 octa-core, 2.7 GHz.
Memory and storage: 6 GB or 8 GB DDR4x RAM with 128 GB UFS flash; user-accessible microSD expansion up to 2 TB.
Display and input: 5.5-inch 2160 x 1080 Full HD multi-touch display with Gorilla Glass 5; glove, stylus, rain, and screen-protector modes.
Scan engine: Standard Range, FlexRange, or FlexRange XLR, depending on option.
Wireless connectivity: Wi-Fi 6E, Bluetooth, NFC, and optional 5G cellular with eSIM plus nano SIM on select configurations.
Ruggedness and sealing: Up to 8 ft drops, 3,500 tumbles at 0.5 m, and IP65/IP68 sealing.
Battery / power: 4,775 mAh standard smart battery on current POSGuys device configurations; warm-swap support.
Form factor, dimensions and weight: Full-touch handheld; 170 x 79 x 19.2 mm (6.69 x 3.11 x 0.76 in); approximately 314 g (11.1 oz) with standard battery.
Warranty: 1 year.

In the Box

Honeywell CT47 mobile computer in the selected configuration
Compatible standard battery for the selected option
Hand strap
USB Type-A to USB Type-C cable
Tamper-resistant T6 screw for the SIM/microSD access door
Product and regulatory documentation

Charging dock, power supply, power cord, protective boot, scan handle, and other accessories are sold separately unless the selected item description explicitly states otherwise.

Capture Across the Operation

Three scan-range choices

Choose Standard Range for everyday barcodes, FlexRange for mixed near-to-far work, or FlexRange XLR for long-distance warehouse and yard scanning.

Fast wireless connections

Wi-Fi 6E supports busy enterprise networks, while select 5G models add cellular coverage for delivery, field service, and mobile workflows.

Built for Demanding Shifts

Rugged Mobility Edge design

High drop and tumble ratings, IP65/IP68 sealing, Gorilla Glass 5, battery analytics, and a broad Honeywell accessory ecosystem support standardized multi-shift fleets.

Dimensions (L x W x D)

170 x 79 x 19.2 mm (6.69 x 3.11 x 0.76 in)

Weight

Approximately 314 g (11.1 oz) with standard battery

Display Size

5.5 in (14 cm)

Resolution

2160 x 1080 Full HD

Keypad

Full touchscreen with on-screen keypad

Audio

Dual microphones with noise cancellation; speaker; Bluetooth audio and push-to-talk support

Interface Ports

USB Type-C and universal-dock contacts; accessory-dependent host and peripheral connections

Operating Temperature

-20°C to 50°C (-4°F to 122°F)

Storage Temperature and Humidity

-30°C to 70°C (-22°F to 158°F); 5% to 95% relative humidity, non-condensing

Drop

Multiple 2.45 m (8 ft) drops to concrete at room temperature; up to 2.75 m (9 ft) with protective boot

Tumble

3,500 tumbles at 0.5 m (1.64 ft); exceeds 2,000 tumbles at 1 m (3.28 ft)

Environmental Sealing

IP65 and IP68

Electrostatic Discharge (ESD)

±15 kV air discharge; ±8 kV direct and indirect contact

CPU

Qualcomm QCS6490/QCM6490 octa-core, 2.7 GHz

Operating System

Android 12 at release; Honeywell-guaranteed support through Android 15

Memory

6 GB or 8 GB DDR4x RAM; 128 GB UFS flash; microSD expansion up to 2 TB

Camera

13-megapixel rear camera and 8-megapixel front camera

Sensors

Ambient light, proximity, accelerometer, gyroscope, magnetometer, pressure, and motion sensors

SIM

Select WWAN models: eSIM plus nano SIM

Battery

4,775 mAh standard smart battery on current POSGuys device options; wireless and extended batteries supported by the platform

Battery Warm Swap

Supported

Hours of Operation

Designed for full-shift operation; runtime varies by configuration, wireless use, and workload

Charging

USB Type-C and Honeywell universal-dock charging; compatible power accessories sold separately

Scan Engine

Standard range, FlexRange, or FlexRange XLR, depending on option

Decode Capabilities

Honeywell 1D and 2D symbologies; supported postal, OCR, and Digimarc decoding varies by scan engine and software

Connectivity

Wi-Fi 6E, Bluetooth, NFC, and optional 5G cellular; VPN and push-to-talk support

WLAN

IEEE 802.11 a/b/g/n/ac/ax with Wi-Fi 6E support; 2x2 MU-MIMO

WLAN Security and EAP

WPA/WPA2/WPA3 Enterprise and Personal; 802.1X/EAP, VPN, and enterprise certificate support

Bluetooth and Second BLE

Bluetooth 5.2 with Bluetooth Low Energy

NFC

Integrated 13.56 MHz NFC supporting ISO/IEC 14443 A/B, ISO/IEC 15693, and MIFARE

WWAN

Select configurations: 5G FR1 and LTE with eSIM plus nano SIM; carrier and regional band support varies by SKU

GPS

Integrated multi-constellation GNSS on WWAN configurations; supports GPS, GLONASS, Galileo, and BeiDou

Application Software

Honeywell Mobility Edge software ecosystem with Operational Intelligence, Enterprise Provisioner, Launcher, and enterprise-management support

Warranty
