UniTech AS10
Simple contact scanning with flexible data formatting
The Unitech AS10 is an economical CCD barcode scanner for retail, medical and light industrial applications. Its built-in decoder reads common linear barcode formats, including GS1 DataBar, at up to 100 scans per second.
The current AS10-U connects by USB and includes a straight interface cable. The historical AS10-P uses a PS/2 keyboard-wedge interface. Its ergonomic ABS housing weighs approximately 120 g without the cable and is rated for a 1.2 m drop.
Key Specifications
- Scanner configuration: Corded handheld CCD
- Barcode capability: 1D, including GS1 DataBar
- Reading range: Contact to about 60 mm, barcode dependent
- Interfaces / connectivity: USB on AS10-U
- Durability: ABS housing; 1.2 m drop
- Environmental sealing: IP rating not specified
- Dimensions: 177 × 75 × 61 mm
- Weight: 120 g without cable
- Warranty: 2 years
In the Box
- Current AS10-U package
- AS10-U barcode scanner, black
- Straight USB interface cable
Format data before it reaches your application
The built-in decoder identifies major barcode symbologies and supports editing scanned data before sending it to the host. This helps match barcode output to the application’s expected input.
Repeat configurations across readers
Barcode menus provide a range of configuration settings. Custom barcode labels let you clone those settings to other AS10 readers for consistent setup.
Shop AS10 Models
AS10-U
Unitech AS10 1D contact CCD barcode scanner, black, USB interface with straight cable included; 2-year warranty.
