Arlo Cash Drawer- iOS Compatible Cash Drawer (Printer Driven) The Arlo cash drawer delivers uncompromising performance and quality, providing a low cost of ownership for light cash-use environments. Purpose-built for the entry-level market, the light duty iOS cash drawer is easy to use, enabling efficiency throughout the checkout process.- • Warranty: 1-Year
- • Return Period: 15 Days
- • Lifetime Support
- • Free Shipping
Practical cash storage for lighter transaction volumes
The APG Arlo is a steel cash drawer for checkout stations that handle a relatively small number of cash payments. Choose the compact 330 or larger 410 footprint, with the till layout and currency arrangement specified by the selected model.
Key Specifications
- Product / application: Light-duty cash drawer
- Till capacity: 330: 4 bill / 5 coin; 410: 5 bill / 5 coin USD or 4 bill / 5 coin CAD, by option
- Media storage: Two front slots with storage beneath the till
- Interface / power: MultiPRO 320-1; 24V printer-driven; CD-101A cable included
- Construction / durability: Steel cabinet and roller wheels; tested beyond 500,000 cycles
- Security: Three-function lock and drawer-open status switch
- Mounting: Countertop; size-specific under-counter brackets sold separately
- Dimensions (W × D × H): 330: 13.2 × 13.5 × 3.5 in.; 410: 16.1 × 16.5 × 3.9 in.
- Warranty: 1 year
In the Box
- APG Arlo drawer in the selected size and color
- Till matching the selected currency configuration
- CD-101A printer cable with 320-1 models
Spare tills, locking covers, and under-counter brackets are sold separately.
Choose the right footprint
The smaller 330 saves counter space. The 410 offers a wider till, with US and Canadian configurations identified in the model list.
Store media without opening
Use the front slots for checks, receipts, or large bills. The status switch lets a compatible POS application monitor whether the drawer is open.
Shop Arlo Models
EKDS320-1-B330-A10
Arlo 13 inch USD, 4x5, MultiPRO Cable Included, Black
Dimensions:
13" × 13"
Bill and Coin:
4 bill / 5 coin
Color:
Black
Currency:
USD
EKDS320-1-B410-A20
Arlo 16 inch USD, 5x5, MultiPRO Cable Included, Black
Dimensions:
16" × 16"
Bill and Coin:
5 bill / 5 coin
Color:
Black
Currency:
USD
EKDS320-1-W410-A20
Arlo 16 inch USD, 5x5, MultiPRO Cable Included, White
Dimensions:
16" × 16"
Bill and Coin:
5 bill / 5 coin
Currency:
USD
Color:
White
EKDS320-1-W330-A10
Arlo 13 inch USD, 4x5, MultiPRO Cable Included, White
Dimensions:
13" × 13"
Bill and Coin:
4 bill / 5 coin
Currency:
USD
Color:
White
EKDS320-1-B410-A21
Arlo 16 CAD, 4x5, MultiPRO Cable Included, Black
Dimensions:
16" × 16"
Bill and Coin:
4 bill / 5 coin
Color:
Black
Currency:
CAD
EKDS320-1-W410-A21
Arlo 16 CAD, 4x5, MultiPRO Cable Included, White
Dimensions:
16" × 16"
Bill and Coin:
4 bill / 5 coin
Currency:
CAD
Color:
White
Shop Arlo Accessories
KPK-27-13-BX
APG 13" Undercounter Mounting Bracket, Arlo Drawer
KPK-27-16-BX
APG 16" Undercounter Mounting Bracket, Arlo Drawer
