TSC Alpha-30L / Alpha-40L
Description
Specifications
Download

TSC Alpha-30L / Alpha-40L

Images may not reflect the actual product
Product Image
small product image0
small product image1
small product image2
small product image3

3- and 4-inch rugged mobile printers

Mobile label printing wherever the work happens

The TSC Alpha-30L and Alpha-40L bring fast direct-thermal label and receipt printing to warehouses, transportation, retail, and field-service teams with durable construction and enterprise wireless choices.

3- or 4-inchMatch the label width to the job
Up to 5 ipsFast mobile label and receipt output
IP54 ratedBuilt for demanding work environments
Wi-Fi or MFiChoose enterprise wireless or Bluetooth

Choose the right configuration

Model family
Resolution
Top speed
Best fit
Alpha-30L
203 dpi
Up to 5 ips
Compact 3-inch receipts, inventory labels, and mobile work
Alpha-40L
203 dpi
Up to 5 ips
Full-size 4-inch shipping and logistics labels

Configuration and workflow choices

Standard and linerless media

Choose peeler-equipped models for conventional media or purpose-built linerless configurations to reduce backing waste.

Reliable connectivity

MFi Bluetooth or dual-band Wi-Fi with Bluetooth support common enterprise mobile deployments.

Designed for motion

IP54 sealing, 6-foot drop resistance, smart batteries, mounts, cases, and charging accessories support full shifts.

What's in the box

Standard package

  • TSC Alpha-30L or Alpha-40L mobile printer
  • Quick start guide
  • Belt clip
  • Rechargeable lithium-ion battery
  • Power adapter
Printing Method
Direct thermal
Resolution
203 dpi
Maximum Print Speed
Up to 5 ips
Peel mode: 2 to 3 ips
Maximum Print Width
Alpha-30L: 2.83 inches (72 mm)
Alpha-40L: 4.09 inches (104 mm)
Maximum Print Length
110 inches (2,794 mm)
Media Types
Continuous, die-cut, black mark, receipt, fanfold and linerless media (configuration dependent)
Media Width
Alpha-30L: 1 to 3.15 inches
Alpha-40L: 2 to 4.4 inches
Media Roll Capacity
2.64-inch outside diameter
Memory
128 MB Flash; 128 MB SDRAM; microSD expansion up to 32 GB
Interfaces
USB-C plus either MFi Bluetooth 5.0 and NFC, or 802.11a/b/g/n/ac Wi-Fi, Bluetooth and NFC
Display and Controls
2.3-inch 320 × 240 color LCD; seven operation buttons
Battery
Alpha-30L: 3,030 mAh rechargeable smart battery
Alpha-40L: 6,200 mAh rechargeable smart battery
Sensors
Reflective and transmissive media sensors; peel-off and head-open sensors
Printer Language
TSPL-EZC; compatible with EPL2, ZPL2 and CPCL; ESC/POS support
Ruggedness
IP54 rated; 6-foot drop; 8.2-foot drop with protective case; 500 tumbles from 3.3 feet
Dimensions and Weight
Alpha-30L: 4.61 W × 6.81 H × 3.11 D inches; 1.64 lb including battery
Alpha-40L: 6.30 W × 7.52 H × 3.11 D inches; 2.17 lb including battery
Operating Environment
-4 to 122°F (-20 to 50°C), configuration dependent
Warranty
Printer: 2 years
Battery: 1 year
Alpha-30L/40L Series Data Sheet
Download
Alpha-30L/40L Series User Manual
Download

Shop Alpha-30L / Alpha-40L Models

A30L-A001-0001

Alpha-30L 3-inch mobile label printer, MFi Bluetooth, factory-installed peeler.

Model:

Alpha-30L

Add Ons:

Peeler

Interface:

USB 2.0, Micro SD, MFi Bluetooth

$846.80

A30L-A001-0011

Alpha-30L 3-inch mobile label printer, MFi Bluetooth, linerless configuration.

Model:

Alpha-30L

Add Ons:

Linerless

Interface:

USB 2.0, Micro SD, MFi Bluetooth

$889.33

A30L-A001-1001

Alpha-30L 3-inch mobile label printer, Wi-Fi and Bluetooth, factory-installed peeler.

Model:

Alpha-30L

Add Ons:

Peeler

Interface:

USB 2.0, Micro SD, Wi-Fi and Bluetooth

$891.93

A30L-A001-1011

Alpha-30L 3-inch mobile label printer, Wi-Fi and Bluetooth, linerless configuration.

Model:

Alpha-30L

Add Ons:

Linerless

Interface:

USB 2.0, Micro SD, Wi-Fi and Bluetooth

$995.28

A40L-A001-0001

Alpha-40L 4-inch mobile label printer, MFi Bluetooth, factory-installed peeler.

Model:

Alpha-40L

Add Ons:

Peeler

Interface:

USB 2.0, Micro SD, MFi Bluetooth

$896.28

A40L-A001-0011

Alpha-40L 4-inch mobile label printer, MFi Bluetooth, linerless configuration.

Model:

Alpha-40L

Add Ons:

Linerless

Interface:

USB 2.0, Micro SD, MFi Bluetooth

$999.92

A40L-A001-1001

Alpha-40L 4-inch mobile label printer, Wi-Fi and Bluetooth, factory-installed peeler.

Model:

Alpha-40L

Add Ons:

Peeler

Interface:

USB 2.0, Micro SD, Wi-Fi and Bluetooth

$995.47

A40L-A001-1011

Alpha-40L 4-inch mobile label printer, Wi-Fi and Bluetooth, linerless configuration.

Model:

Alpha-40L

Add Ons:

Linerless

Interface:

USB 2.0, Micro SD, Wi-Fi and Bluetooth

$1105.87
Have Questions?Call Us at: (800) 241-6264
