Elo TouchSystems AI Edge Pack

Name: Elo TouchSystems AI Edge Pack
Brand: Elo TouchSystems
Price: 11968.18 USD
Availability: InStock

Images may not reflect the actual product

Intel Core i9 edge computing with NVIDIA or Hailo acceleration.

Elo AI Edge Pack brings AI and data-intensive workloads closer to where data is created. The North American configurations pair an Intel Core i9-14900 processor with 96GB DDR5 memory, a 1TB NVMe SSD and either an NVIDIA GeForce RTX 5080 GPU or Hailo 0808S neural accelerator.

Local processing reduces cloud round-trips and data transfers for automation, real-time control and AI applications. Four 2.5GbE LAN ports and extensive USB and video connections support connected edge deployments. Both listed configurations ship with No OS; operating system and application software are required separately.

Elo AI Edge Pack NVIDIA RTX 5080 configuration

Key Specifications

Processor: Intel Core i9-14900, up to 5.8GHz
Memory / storage: 96GB DDR5-5600; 1TB NVMe SSD installed
AI accelerator: NVIDIA GeForce RTX 5080 16GB or Hailo 0808S
Operating system: No OS; software supplied separately
Display / touch: External displays required; HDMI, DisplayPort and VGA
Network / USB: Four 2.5GbE LAN ports and eight USB 3.0 ports
Mount / stand: Compact enclosure for shelf or edge installations
Peripheral options: External cameras, sensors and USB devices; compatibility depends on the peripheral
Serviceability: Serviceable internal components; replaceable clock battery
Power: 850W supply; 100–240V AC, 50–60Hz
Environment: 0–35°C operation; specified airflow required
Dimensions / weight: 344 × 356.7 × 174.2 mm; 8–8.9 kg, model dependent
Warranty: 3 years

In the Box

Selected North American AI Edge Pack computer
North America power cord
Quick Installation Guide
Cable tie

Process data at the edge

Run workloads locally to reduce the delay and bandwidth associated with cloud round-trips. The platform supports automation, real-time control and data-heavy AI applications; accelerator capability depends on the selected configuration.

Room for evolving workloads

The platform supports up to 192GB DDR5 memory and up to 4TB storage, with dual M.2 NVMe slots and RAID capability varying by model. The listed systems include 96GB RAM and one 1TB SSD; expansion components are sold separately.

Product type

Elo AI Edge Pack commercial edge computing system; external displays required

Enclosure color

Black

North America configurations

E540147: NVIDIA GeForce RTX 5080; E704846: Hailo 0808S. Both: Intel Core i9-14900, 96GB RAM, 1TB SSD, No OS and North America power cord

Operating system

No OS; operating system, license and application software supplied separately

Processor

Intel Core i9-14900, 36MB Smart Cache, up to 5.80GHz

Chipset

R680E

Integrated graphics

Intel Graphics

BIOS

AMI; Secure Boot enabled by default

Memory

96GB DDR5-5600 U-DIMM installed across three slots; expandable to 192GB maximum across four slots, varying by model

Storage

1TB M.2 PCIe NVMe SSD installed; platform supports dual M.2 slots, RAID capability and up to 4TB storage, varying by model

PCIe x16 accelerator

E540147: NVIDIA GeForce RTX 5080 Solid Core OC 16GB; E704846: Hailo 0808S

AI performance

Manufacturer platform claim: up to 1800 TOPS; performance depends on the accelerator and workload and does not describe every configuration

Network ports

Four RJ45 2.5 Gigabit Ethernet ports

USB ports

Eight USB 3.0 ports

Base video connections

Two DisplayPort, one HDMI and one VGA

NVIDIA additional video connections

E540147 add-in card provides three additional DisplayPort and one additional HDMI output

Audio connections

Three 3.5 mm audio ports: line in, line out and microphone in

TPM

TPM 2.0

Controls / indicators

Power button; power LED off when off, green when on and flashing green in sleep

Power supply

850W; 100–240V AC input, 50–60Hz. Maximum continuous total output 850W; combined +3.3V and +5V output must not exceed 100W

Power output rails

Manufacturer ratings: 66W at 3.3V, 100W at 5V and 849.6W at 12V; shared output limits apply

Typical power consumption

Without peripherals: E540147 NVIDIA 660W; E704846 Hailo 280W; sleep 3.4W; off 0.7W

Dimensions

344 × 356.7 × 174.2 mm (13.54 × 14 × 6.86 in)

Device weight

NVIDIA: 8.9 kg / 19.4 lb; Hailo: 8 kg / 17.6 lb, manufacturer published values

Shipping dimensions

470 × 470 × 370 mm (18.5 × 18.5 × 14.5 in)

Packaged weight

NVIDIA: 13 kg / 28.6 lb; Hailo: 10.3 kg / 22 lb, manufacturer published values

Operating temperature

0–35°C (32–95°F); manufacturer thermal qualification uses 0.5 m/s airflow and CPU minimum assured power condition

Storage temperature

−20–60°C (−4–140°F)

Humidity

Non-condensing: operating 20–80% RH; storage 5–95% RH, maximum 38.7°C wet-bulb temperature

Real-time clock

Replaceable CR2032 lithium-metal coin-cell battery

Serviceability

Serviceable internal components

Regulatory

Canada cUL/IC; United States UL/FCC; RoHS CoC; Japan VCC; International CB, per manufacturer declaration

Included items

Selected North America AI Edge Pack, North America power cord, Quick Installation Guide and cable tie

Extended services

Optional: E819598 4-year; E819795 5-year; E820186 3-year plus AUR; E820388 4-year plus AUR; E820582 5-year plus AUR. Eligibility and service terms apply

Warranty

3 years

Shop AI Edge Pack Models

E540147

Elo AI Edge Pack, Intel Core i9-14900, 96GB DDR5 RAM, 1TB NVMe SSD, NVIDIA GeForce RTX 5080 16GB accelerator, four 2.5GbE LAN ports, No OS, North America power cord, black

AI Accelerator:

NVIDIA GeForce RTX 5080 16GB

$13590.80

E704846

Elo AI Edge Pack, Intel Core i9-14900, 96GB DDR5 RAM, 1TB NVMe SSD, Hailo 0808S neural accelerator, four 2.5GbE LAN ports, No OS, North America power cord, black

AI Accelerator:

Hailo 0808S

$11968.18
