Honeywell Voyager 1200g

Images may not reflect the actual product
Product Image
small product image0
small product image1
small product image2
small product image3
small product image4

Best value hands free, top performing linear scanner.

The Honeywell Voyager 1200g barcode scanner builds on the strengths of its predecessor, giving you aggressive scanning performance on virtually all linear barcodes. Honeywell has gone to tremendous lengths to give you the best scanning experience possible, and with the Voyager 1200g you get it. Damaged, crumpled, low contrast and nearly destroyed barcodes are no match for the Voyager 1200g, speeding up the scanning process and saving you time. The Voyager 1200g's contact to 10" optimal scan range is ideal for retail scanning, and the included autosense stand allows for presentation scanning with no configuration.

The Voyager 1200g improves on the original Voyager's durability, further extending the life of your barcode scanner. The scan button is now covered with a rubber gasket, keeping dirt, dust, and water splashes out from harming internal components, at an IP42 seal rating. Honeywell designed the internal components to fit on a single shock-mounted circuit board, increasing its resistance to damage from drops and collisions.

Features
• IP42 seal keeps out dirt and water
• 10" optimal scan range for 13 mil UPC barcodes
• CodeGate technology ensures greater scanning accuracy
• Included stand automatically switches scanner into autosense mode
• Can scan in direct sunlight
• Reads barcodes as small as 3.5 mil

Dimensions
3.0 x 7.1 x 3.8 in (66mm x 180mm x 97mm)
Weight
4.4oz (125g)
Color Options
Black<br> Ivory
Interfaces Available
Multi-Interface / Includes RS232 (TTL +5V, 4 Signals) / KBW / USB (HID Keyboard, Serial, IBM OEM); RS-232C (+/-12V) and IBM RS485 supported via adapter cable
Scan Method
Single-Line Laser
Decoding Capabilities
Reads standard 1D and GS1 DataBar symbologies
Mobility/Range
Corded
Scan Rate (Maximum)
100 scan lines/second
Reading Angle
Pitch: 60° <br>Skew: 60°
Print Contrast (Min.)
10% minimum reflectance difference
Typical Depth of Field
5 mil: 40mm - 129mm (1.6 - 5.1in)<br>7.5 mil: 27mm - 185mm (1.1 - 7.3in)<br>10 mil: 0mm - 221mm (0 - 8.7in)<br>13 mil: 0mm - 254mm (0 - 10.0in)<br>20 mil: 0mm - 281mm (0 - 11.1in)
Indicators
Beep<br>CodeGate® Technology
Auto Sense Mode
Yes, In Stand
Operating Temperature
0°C to 50°C (32°F to 122°F)
Drop Specification
Designed to withstand 30 drops to concrete from 1.5 m
Environmental Sealing
IP42
Ambient Light (Max)
0 - 70,000 lux
Stand
Yes, Included
Warranty
5 year factory warranty
Data Sheet (English)
Download
OPOS Driver (Optional)
Download
USB Serial Driver (Optional)
Download
Data Sheet (Español)
Download
Manual (English)
Download
Quick Start Guide (English)
Download
Quick Start Guide (Español)
Download

Shop Voyager 1200g Windows Models

1200G-2USB-1-N

Voyager 1200g Barcode Scanner, Black with Scanner and Stand, USB Interface

Color:

Black

Accessories:

Stand

Interface:

USB

$149.01

1200G-1USB-1-N

Voyager 1200g Barcode Scanner, Ivory with Scanner and Stand, USB Interface

Color:

Ivory

Accessories:

Stand

Interface:

USB

$164.04

1200G-2USB-1

Voyager 1200g USB Kit: 1D, black scanner (1200g-2), rigid presentation stand (STND-19R02-002-4), US Bluetooth, type A 3m coiled cable (CBL-500-300-C00) and documentation

Color:

Black

Accessories:

Stand

Interface:

USB

$211.37

1200G-1USB-1

Voyager 1200g USB Kit: 1D, ivory scanner (1200g-1), rigid presentation stand (STND-19R02-002-4), USB Type A 3m coiled cable (CBL-500-300-C00) and documentation

Color:

Ivory

Accessories:

Stand

Interface:

USB

$236.49

1200G-2-N

Voyager 1200g Barcode Scanner, Black, Scanner Only, 1D, RS232, USB, Keyboard Wedge, IBM - Requires Cable

Color:

Black

Accessories:

Not Included

Interface:

USB

$140.28

1200G-1

Voyager 1200g Barcode Scanner, Ivory, 1D, USB Interface - CABLE SOLD SEPARATELY

Color:

Ivory

Accessories:

Not Included

Interface:

USB

$252.46

Shop Voyager 1200g Accessories

E-SVC1200g-S

Voyager 1200g - 1-Year Warranty, 3-day turnaround, Wear, Post Sales

$8.00

CBL-500-300-C00

USB Interface Cable, Black, 3 Meter, Coiled

$27.04

CBL-500-300-S00

USB Interface Cable, Black, 3 Meter, Straight

$27.04

CBL-500-500-C00

USB Interface Cable, Black, 5m Length

$29.76

STND-19R02-002-4

Honeywell, Voyager 1200g, Gray Presentation Stand, 19cm (7.5 in.) Stand Height, Rigid Voyager-Like Plastic Pole, Weighted Tripod Base, Voyager 1200 Cup

$41.00

SVC1200G-1LC5

Voyager 1200g - 5-Year Warranty, 1-day turnaround, comprehensive coverage - replaces SVC1200g-SMS5

$37.80
