Epson TM-T20IV

Name: Epson TM-T20IV(Windows)
Brand: Epson
Price: 234 USD
Availability: InStock

Images may not reflect the actual product

The capable, affordable POS printer with versatile connectivity

Engineered for a balance of speed, reliability and affordability in a compact package, the TM-T20IV thermal receipt printer is purpose-built for taking on the demanding POS needs of today’s businesses. This versatile printer supports traditional PC-POS and mPOS systems and features two built-in connectivity options, allowing for exceptional flexibility and productivity: (1) USB with serial connectivity and (2) USB with serial and Ethernet connectivity. The TM-T20IV is built for productivity—with print speeds up to 250 mm/sec, an intuitive status LED and paper savings of up to 30 percent, it’s the ideal solution for keeping your POS workflow moving quickly and efficiently. The printer is backed by a 2-year limited warranty, with extended service plan options available up to a total of 5 years of continuous coverage, giving you Epson’s world-class service and support for your peace of mind.

Features

Engineering meets affordability — practical features are designed for today’s POS needs
Compact, modern design — small 3" thermal receipt printer
Designed for reliability — 2-year limited warranty; extended service plans, including Spare-in-the-Air™ coverage, are available
Multiplatform support — compatible with traditional PC-POS and mPOS devices
Versatile connectivity — offers two built-in interface options: USB with serial or USB with serial and Ethernet connectivity
Fast printing — print speeds up to 250 mm/sec allow for fast transactions
Paper-saving functions — top-margin and character-height reduction features help reduce paper by up to 30 percent1
Easy to use — status LED with intuitive icons allows for simple troubleshooting and maintenance

What's in the box:

Epson TM-T20IV thermal receipt printer
Thermal roll paper (starter roll)
USB cable
Power Adapter
AC cable
Wall hanging bracket
Setup guide

Print Method

Thermal line printing

Print Speed

Max. 250 mm/sec

Fonts

9 x 17 and 12 x 24 dots/character (W x H)

Print Resolution

203 dpi

Column Capacity

Standard: <ul> <li>Paper width 80 mm: 48/64 columns</li> <li>Paper width 58 mm: 35/46 columns</li></ul> <br>42-column Mode: <ul><li>Paper width 80 mm: 42/60 columns</li> <li>Paper width 58 mm: 42/31 columns</li></ul>

Character Size (W x H)

0.08 x 2.13 mm and 1.25 x 3.00 mm

Character Set

95 Alphanumeric, 18 International, 128 x 43 Graphic

Barcode

UPC-A/E, JAN 13 (EAN 13), JAN 8 (EAN), Code 39/93/128, CODABAR (NW-7), Composite Symbology, GS1-128, GS1 DataBar, ITF

Characters Per Inch

22.6 and 16.9 cpi

Media Dimensions

<ul> <li>80 mm: 79.5 ± 0.5 x 83 mm 3.13" ± 0.02" (width) x 3.27" (roll diameter)</li> <li>58 mm: 57.5 ± 0.5 x 83 mm 2.26" ± 0.02" (width) x 3.27" (roll diameter) Thickness 53 – 75 µm</li> </ul>

Interface (Dual-Interface Model)

<ul><li>USB Type-B</li> <li>Serial RS-232 D-Sub 25pin</li></ul>

Interface (Triple-Interface Model)

<ul> <li>USB Type-B</li> <li>Serial RS-232 D-Sub 9pin</li> <li>Ethernet (10/100Base-T/TX)</li> <li>USB Type-A for peripheral device</li> <li>Optional Wi-Fi® via OT-WL06 USB adapter Dongle (2.4 GHz/5.0 GHz)</li> </ul>

Printing From a Mobile Device

Supported (mobile) operating systems: iOS®, Android® and Windows® operating systems

Epson ePOS Technology

Supports ePOS service for direct printing from mobile devices or web-based applications

D.K.D.

2 drivers

Dimensions (W x D x H)

5.51" x 7.83" x 5.75" (140 mm x 199 mm x 146 mm)

Weight

3.75 lb (1.7 kg)

EMI Standards

FCC Class A, ICES-003 Class A

Safety Standards

UL62368-1, CAN/CSA C22.2 No.62368-1

Case Color

Epson Black

Reliability

<ul> <li>MTBF: 360,000 hours</li> <li>MCBF: 60,000,000 lines</li> <li>Auto cutter: 2 million cuts</li> </ul>

Options

External buzzer unit (0T-BZ20)

Installation

Horizontal/vertical on counter/vertical on wall with wall hanging bracket

Power Supply Voltage

24 VDC ± 7%

Power Consumption

<ul><li>Operating: Approx. 27.2 W<li> <li>Standby: Approx. 0.96 W<li> </ul>

Power Source

AC power consumption (AC 100 to 230 V/50 to 60 Hz) (AC cable included)

What’s Included

Epson TM-T20IV thermal receipt printer, thermal roll paper (starter roll), USB cable, Power Adapter, AC cable, wall hanging bracket, setup guide

Warranty

2-year limited in the U.S. and Canada; optional extended service plans available

Shop TM-T20IV Windows Models

C31CL47001

TM-T20IV Receipt Printer, Thermal, Serial & USB, Black, Power Supply

$234.00

C31CL47002

TM-T20IV Receipt Printer, Thermal, Ethernet, Serial & USB, Black, Power Supply

$353.00

Shop TM-T20IV Accessories

C825343

PS-180 Power Supply For Epson Receipt Printers (120/220V). Includes AC Cord (205498100). Energy Star Rated.

$56.16

XWP-T220-10-ADD

Thermal Receipt Paper Promo Pack (10 Pack of Rolls) - 3.125" Wide x 220 ft. BPA FREE. (Price is for First Promo Pack Only. Ground Shipping Only)

$40.00

EPPSDEXTA3

Epson Three Year Extended Warranty Coverage for Epson TM-T TM-L & TM-m Receipt Printer. Adds 3 Additional Years of Coverage to a Printer's Standard Warranty. Two-Way Shipping Is Included By Epson.

$128.41

EPPSDSITAA3

Epson 3-Year Spare-in-the-Air Advanced Replacement Warranty For All TM-T TM-L TM-M and DM Series Receipt Printers. Includes Paid Two-Way Next Business Day Shipping of Replacement Unit.

$109.58
