MicroTouch Mach Series

Images may not reflect the actual product
Product Image
small product image0
small product image1
small product image2
small product image3

The Mach Series of desktop touch monitors are designed to bridge the gap between consumer aesthetics and the next generation of interactive commercial technologies. Available in a 15-inch, 21-inch and 24-inch screen size, the Mach Series is engineered for durability and performance.

New to the Mach Series is an optically bonded touch screen. This drives industry leading optical clarity, picture quality and touch targeting while increasing durability. With the screen's advanced etched anti-glare process, you'll benefit from improved light dispersion and wear overtime. Ranging from bright retail environments to harsh industrial applications, this display has the versatility and performance that sets the standard. Featuring 4 x USB-C peripheral connections and a versatile I/O design, this display is a perfect fit for a variety of applications.

Highlighted Features

  • Size: 15.6" / 21.5" / 23.8" TFT LCD
  • Maximum Resolution: 1920 x 1080
  • Aspect Ratio: 16:9
  • Video Port: 1 x HDMI (up to 1920 x 1080 @60Hz)
  • Touch Interface: USB-HID (Type C)
Touch Screen
Projected Capacitive
Touch Interface
USB-HID (Type C)
USB Ports
1 x USB-C (ALT mod for DP video/power acceptance), 4 x USB-C (peripheral connection), 1 x USB 3.1 Type A
Video Port
1 x HDMI (up to 1920 x 1080 @60Hz)
Power Supply
60W External AC Power Adaptor (100VAC ~240VAC, 50/60Hz)
Construction
Plastic, Glass, SECC Metal
Environmental seal
IP65 – Front only
Dimensions (H x W x D)
15.6" - 14.88″ x 8.95″ x 1.26″ (monitor only)<br> 21.5" - 20.29″ x 12.08″ x 1.61″ (monitor only) / 20.29″ x 12.08″ x 4.39″ (with stand)<br> 23.8" - 22.51″ x 13.44″ x 1.66″
VESA Mount Capable
100 x 100 mm
Operating Temperature
0˚C ~ 40˚C, 20% ~ 80% RH. Non-Condensing
Microtouch Mach Series 15-inch Spec Sheet
Download
Microtouch Mach Series 21-inch Spec Sheet
Download
Microtouch Mach Series 24-inch Spec Sheet
Download
MicroTouch Mach Series User Manual
Download

Shop Mach Series Windows Models

M1-156DT-A1

Mach Series 15.6" Desktop Touch Monitor (1920 x 1080). Stand Included.

$623.00

M1-215DT-A1

Mach Series 21.5" Desktop Touch Monitor (1920 x 1080). Stand Included.

$665.50

M1-238DT-A1

Mach Series 24" Desktop Touch Monitor (1920 x 1080). Stand Not Included.

$665.50

Shop Mach Series Accessories

vesa-screw-pack

Screw Pack for Monitors M4 0.7 (4 screws)

$11.00

SS-156-A1

100X100 VESA Slim Stand

$64.50

MT-BRKT-DD-A1

Dual Display Bracket

$21.00

MA-STAND-A2

Mach Stand

$110.68
