ENHANCED LINEAR IMAGING TECHNOLOGY
The Gryphon 4200 series represents the premium range of handheld
scanners from Datalogic for value added applications.
The Gryphon 4200 linear imagers stand out with unchallenged ergonomics
and outstanding reading performance. The Gryphon 4200 readers’ ability
to capture bar codes from near to far, to read both high-density and low
resolution codes, to decode hard-to-read, poorly printed or damaged
codes and to easily read bar codes from mobile devices make these
imagers the perfect choice for today’s applications.
The Gryphon 4200 scanners utilize Datalogic’s Motionix™ technology
to automatically switch into the ‘ready-to-read’ scanning mode and to
activate the distinctive ‘soft line viewfinder’ which helps the operator to
easily target the code to be read.
The Datalogic’s ‘Green Spot’ for good-read feedback directly on the code is
ideal under dim lighting conditions or noisy environments.
Features
Enhanced linear imaging technology for superior scanning and Depth of Field
Reads 1D high-density and low-resolution codes, hard-to-read, poor or damaged codes
and bar codes from mobile devices
Datalogic’s ‘Green Spot’ technology and 3GL™ (3 Green Lights) for superior good-read
feedback
Choice of Bluetooth wireless technology or Datalogic’s STAR Cordless System (radio
frequencies available in 433 MHz or 910 MHz)
Disinfectant-Ready enclosures withstand daily cleaning with harsh disinfectant solutions
Dimensions
16.6 x 6.8 x 10.9 cm / 6.5 x 2.7 x 4.3 in (corded/cordless
models)
Weight
163.0 g / 5.75 oz (corded models)
235 g / 8.29 oz (cordless models, battery included)
Color Options
Black & White
Interfaces
CORDLESS MODELS:
WLC4190: USB Type C / USB / RS-232 / Keyboard Wedge
Multi-Interface
WLC4090: USB / RS-232 / Keyboard Wedge MultiInterface
CORDED MODELS:
GD4220: USB type C / USB only
GD4290: USB type C / USB / RS-232 / Keyboard Wedge
Multi- Interface
Mobility/Range
Bluetooth 100.0 m / 328.0 ft | Radio 50.0 m / 164.0 ft
