MicroTouch Digital Signage Series
The MicroTouch Digital Signage series encourages effective and efficient user collaboration and engagement. The ultra-slim build coupled with advancements in touch technology ensures that every user interaction is effortless and effective. Whether it is collaborative applications, way-finding capabilities, or custom branded kiosks, this touch solution retains everything desired in a large format touchscreen. Special Anti-Glare and Anti-Fingerprint screen treatments are available on certain models (please see specification table below for more details.
31.5" Display Features- Size: 31.5” TFT LCD
- Maximum Resolution: 1920 x 1080
- Contrast Ratio: 1200:1
- Aspect Ratio: 16:9
- Brightness: 400 nits (w/o Touch), 360 nits (P-CAP)
- Video Port: 1 x VGA, 1 x DVI-D, 1 x HDMI
43" Display Features
- Size: 43” TFT LCD
- Maximum Resolution: 1920 x 1080
- Contrast Ratio: 4000:1
- Aspect Ratio: 16:9
- Brightness: 400 nits (w/o Touch), 328 nits (P-CAP)
- Video Port: 1 x VGA, 1 x HDMI 1.3, 1 x DP 1.2, 1 x DVI
- Serial Port: 1x RJ11 (for Remote Key)
- Screen Treatment: Anti-Glare
4K 43" Display Features
- Size: 43” TFT LCD
- Maximum Resolution: 3840 x 2160
- Contrast Ratio: 1000:1
- Aspect Ratio: 16:9
- Brightness: 400 nits (w/o Touch), 360 nits (P-CAP)
- Video Port: 1 x HDMI 1.4, 1 x HDMI 2.0, 1 x DVI-I, 1 x DP 1.2
- Serial Port: 1x RJ11 (for Remote Key)
- Screen Treatment: Anti-Fingerprint
55" Display Features
- Size: 31.5” TFT LCD
- Maximum Resolution: 3840 x 2160
- Contrast Ratio: 1100:1
- Aspect Ratio: 16:9
- Brightness: 500 nits (w/o Touch), 425 nits (P-CAP w/AG coating)
- Video Port: 1 x HDMI 1.4, 1 x HDMI 2.0, 1 x DVI-I, 1 x DP 1.2
- Serial Port: 1 x RJ11 (for Remote Key)
- Screen Treatment: Anti-Glare
Drivers for this unit can be downloaded here
Shop Digital Signage Series Windows Models
DS-320P-A2
MicroTouch, 31.5" Digital Signage, 1920X1080, VGA/DVI-D/HDMI, 10 Touch Points, PCAP, 400NITS, NO MOUNT, 400X200 MM VESA Compatible, 3 Year Warranty
DS-320P-A1
31.5" PCAP Digital Signage Series LCD Touch Monitor. IP65. USB for Touch. VGA, DVI-D, HDMI for Video. 1920x1080.
DS-430P-A1
43" PCAP Digital Signage Series LCD Touch Monitor. Anti-Glare, IP65. USB for Touch. VGA, DVI-D, DP, HDMI for Video. 1920x1080.
DS-430P-A2
43" PCAP Digital Signage Series LCD Touch Monitor. Anti-Fingerprint, IP65. USB for Touch. VGA, DVI-D, DP, HDMI for Video. 3840x2160.
DS-430P-B2
MicroTouch, 43'' Digital Signage, 3840X2160, VGA/HDMI/DP/DVI, 40 Touch Points, PCAP, 500 NITS(NO TOUCH),450 NITS(PCAP), NO MOUNT, 400X400 MM VESA Compatible, 3 Year Warranty
DS-550P-A1
55" PCAP Digital Signage Series LCD Touch Monitor. Anti-Glare, IP65. USB for Touch. VGA, DVI-D, DP, HDMI for Video. 3840x2160.
